Rectangular aluminium frame with dark metal blades, 172 by 150 by 38 mm, 230 V AC industrial fan

SXDOOL

SXDOOL UT797C-TP[B13] 230V 172x150x38mm iron leaf case fan

SKU CH-WV8M-BDHE5

A 230 VAC aluminium-frame case fan with iron blades, running at 2650 or 3100 r/min and moving 4.8 or 5.7 m³/min at 55 to 58 dB(A)

  • TypeCase Fan
  • Aluminium frame resists corrosion for long service life
  • Iron blades withstand high temperatures in demanding environments
  • Dual-speed motor delivers 2650 or 3100 rpm for flexible airflow
  • 230 VAC operation suits industrial and server power supplies
  • 55 to 58 dB(A) noise level keeps acoustic impact low

SXDOOL UT797C-TP[B13] 230V AC case fan

The SXDOOL UT797C-TP[B13] is a 172 by 150 by 38 millimetre case fan built with an aluminium frame and iron blades rated for high-temperature operation. It runs directly from 230 volt AC mains at 50 or 60 hertz, drawing 0.26 or 0.22 amps depending on line frequency. This unit suits industrial enclosures or server chassis that require mains-powered airflow without an external power supply. It is not for builders who need a low-voltage PWM fan for standard motherboard headers.

230 volt AC mains voltage

The defining specification is the 230 volt AC input, which removes the need for a DC power conversion stage but limits use to equipment wired for mains voltage. At 50 hertz the fan spins at 2650 revolutions per minute, moves 4.8 cubic metres of air per minute and develops 104 pascals of static pressure at 55 decibels. At 60 hertz speed rises to 3100 revolutions per minute, airflow to 5.7 cubic metres per minute and static pressure to 107 pascals at 58 decibels. Power draw is 36 watts at 50 hertz and 31 watts at 60 hertz.

Aluminium frame with iron blades

The aluminium frame and iron leaf blades are designed to withstand elevated operating temperatures inside dense equipment racks. No mounting screws, wiring harnesses or speed-control accessories are mentioned in the supplier data, so installers must provide their own fixation and electrical connection. The bare-lead mains connection demands appropriate insulation and strain relief to meet safety standards.

Highlights

  • Aluminium frame resists corrosion for long service life
  • Iron blades withstand high temperatures in demanding environments
  • Dual-speed motor delivers 2650 or 3100 rpm for flexible airflow
  • 230 VAC operation suits industrial and server power supplies
  • 55 to 58 dB(A) noise level keeps acoustic impact low

Specifications

TypeCase Fan

Questions about this item

What does the 4.8 and 5.7 m³/min airflow mean once the fan is installed in a case?

The fan moves 4.8 cubic metres per minute at 50 Hz and 5.7 at 60 Hz, so a typical chassis will see roughly that volume of air pushed through the mesh or radiator.

How does the 230 VAC 50/60 Hz supply affect what the fan can actually draw?

It runs directly from mains at 0.26 A on 50 Hz and 0.22 A on 60 Hz, consuming 36 W and 31 W respectively with no external adapter needed.

Will the 172×150×38 mm aluminium frame with iron blades fit a standard 172 mm mounting pattern?

Yes, the frame matches the 172 mm square bolt pattern and is 38 mm thick, so it bolts into any cut-out designed for that footprint.
