Black 90 mm square frame fan with USB cable visible

SXDOOL

SXDOOL R9225H05BPLB1 90 mm case fan 5 V 3000 RPM

SKU CH-R9SM-62VMC MPN R9225H05BPLB1

A 90 mm double ball bearing case fan runs at 3000 RPM on 5 V USB power, delivering 55.19 CFM airflow at 35.73 DBA with a 50000-hour rated life

  • 5 V USB power runs from a power bank or laptop port
  • 90 mm frame fits tight 92 mm mounts in small-form-factor cases
  • Double ball bearing rated for 50000 hours of continuous use
  • 3000 RPM delivers 55.19 CFM airflow at 35.73 dBA
  • 60 cm cable reaches motherboard headers without extensions

90 mm 5 V USB case fan

The SXDOOL R9225H05BPLB1 is a 90 mm square frame fan that runs from a standard 5 V USB header. It uses a double ball bearing rated for 50000 hours of operation at 3000 RPM. The 60 cm cable reaches most motherboard headers or external power banks.

Suited to tight intake or exhaust spots

Builders who need a slim 25 mm thick fan with USB power will fit this into compact chassis, small form factor cases or peripheral cooling brackets. Buyers who require PWM speed control or a traditional 3-pin or 4-pin motherboard connector should look elsewhere.

55.19 CFM airflow at 35.73 dBA

The single figure that decides fit is the 55.19 CFM air volume delivered at the rated 35.73 dBA noise level. If that airflow meets the thermal target the fan is the right part; if more flow or quieter running is needed a different specification is required.

Highlights

  • 5 V USB power runs from a power bank or laptop port
  • 90 mm frame fits tight 92 mm mounts in small-form-factor cases
  • Double ball bearing rated for 50000 hours of continuous use
  • 3000 RPM delivers 55.19 CFM airflow at 35.73 dBA
  • 60 cm cable reaches motherboard headers without extensions

Specifications

No published specifications for this item yet.

Questions about this item

How can I confirm the 90 mm fan is running at its rated 3000 RPM after connecting the USB cable?

The fan supports speed measurement, so you can monitor the 3000 RPM reading through motherboard software or a fan controller once the USB cable is plugged in.

What comes with the R9225H05BPLB1 and is a separate power adapter needed?

The package includes the 90×90×25 mm double ball bearing fan with a 60 cm USB interface cable; no extra adapter is required because it draws 0.80 A directly from a 5 V USB port.

Which version of this 9025-size fan should I choose for a 5 V USB header?

The R9225H05BPLB1 is the 5 V, 3000 RPM model with a USB cable, making it the correct choice for a 5 V USB header.
