Square 92mm slim case fan, black PBT frame, transparent blades, 4-pin PWM connector

SXDOOL

SXDOOL 9015 92mm case fan 90x90x15mm 4-pin PWM

SKU CH-JDHC-2FHSJ

A 92 mm slim case fan with 4-pin PWM control, ball bearing and 3200 rpm maximum speed delivering 37.61 CFM at 36.5 dB(A)

  • TypeCase Fan
  • Fan Size92mm
  • Bearing TypeBall
  • Power Connector4 Pin
  • Slim 15 mm profile fits tight 92 mm mounts
  • 4-pin PWM gives motherboard speed control from 7.0 V to 13.8 V
  • Double ball bearing rated for 100 000 hours at 25 °C
  • 3200 rpm delivers 1.11 m³/min airflow at 36.5 dB(A)
  • PBT frame and blades with V0 flame retardant withstand -30 °C to 75 °C

92 mm PWM case fan for compact builds

The SXDOOL 9015 is a 92 mm square frame fan measuring 15 mm thick. It runs on 12 V DC with a 4-pin PWM connector for automatic speed control. The unit suits small-form-factor chassis, CPU coolers or any mount that accepts a 90 mm hole pattern.

Straightforward 4-pin mounting with standard spacing

Installation uses four corner screws through the PBT frame; the 4-pin header plugs directly into a motherboard PWM header. The double ball bearing is maintenance-free, but the 15 mm slim profile leaves little room for cable routing behind the frame. Verify clearance against nearby components before securing the fan.

3200 rpm maximum speed at 36.5 dB(A)

At full rated voltage the motor spins to 3200 rpm ±10 % and delivers 1.11 m³/min (37.61 CFM) of airflow. The noise rating at that speed is 36.5 dB(A). If your thermal target requires higher static pressure or lower acoustic output, this specification may not meet the need.

Highlights

  • Slim 15 mm profile fits tight 92 mm mounts
  • 4-pin PWM gives motherboard speed control from 7.0 V to 13.8 V
  • Double ball bearing rated for 100 000 hours at 25 °C
  • 3200 rpm delivers 1.11 m³/min airflow at 36.5 dB(A)
  • PBT frame and blades with V0 flame retardant withstand -30 °C to 75 °C

Specifications

TypeCase Fan
Fan Size92mm
Bearing TypeBall
Power Connector4 Pin

Questions about this item

How can I confirm the fan is running at its rated 3200 RPM after installation?

Use BIOS or monitoring software to read the 4-pin PWM speed signal; the fan should report near 3200 RPM under full load.

What comes in the box and do I need any extra cables or screws?

The package contains the 90 × 90 × 15 mm fan with a 4-pin PWM connector; mounting screws and any adapter cables are not included.

Should I choose the 92 mm ball-bearing model or a different size for my chassis?

Select this 92 mm, 15 mm-thick, ball-bearing fan when your case has 90 mm mounting holes and you need PWM control within a 7.0–13.8 V range.
