Square 80mm case fan with black frame and clear blades, three-pin connector visible

SXDOOL

SXDOOL 0825-12HBTL 80mm 12V 0.35A 3-pin case fan

SKU CH-6TGC-7YDJS MPN 0825-12HBTL

An 80 mm case fan with temperature-controlled speed from 1400 to 3800 RPM, delivering 15 to 35.50 CFM at 8 to 21.3 dBA on a 3-pin connector

  • Fan Size80mm
  • Power Connector3 Pin
  • Temperature-controlled speed keeps noise low at 8 dBA
  • Automatic RPM range 1400–3800 matches cooling demand
  • Double-ball bearing extends operational life
  • 5 CFM maximum airflow clears heat efficiently
  • 3-pin connector fits standard motherboard headers

80mm temperature-controlled case fan

The SXDOOL 0825-12HBTL is an 80mm case fan designed for system cooling where automatic speed regulation is required. It suits builders fitting compact chassis or replacing original cooling in legacy hardware. The double ball bearing supports continuous operation at 12 volts.

Check 3-pin header and 80mm mounting

Verify that your motherboard or fan controller provides a standard 3-pin header for power and speed signal. The frame measures 80 by 80 by 25 millimetres, so confirm the mounting holes match this spacing. The white wire carries the temperature probe signal and can be left disconnected if only two-wire operation is needed.

Probe enables automatic speed curve

A built-in temperature probe adjusts rotational speed between 1400 and 3800 RPM without software intervention. Airflow scales from 15 to 35.50 CFM while noise ranges from 8 to 21.3 dBA. The fan cable includes three wires compatible with standard headers and specific Dell motherboard connectors.

Highlights

  • Temperature-controlled speed keeps noise low at 8 dBA
  • Automatic RPM range 1400–3800 matches cooling demand
  • Double-ball bearing extends operational life
  • 5 CFM maximum airflow clears heat efficiently
  • 3-pin connector fits standard motherboard headers

Specifications

Fan Size80mm
Power Connector3 Pin

Questions about this item

What comes in the box with the SXDOOL 0825-12HBTL fan and is a mounting kit included?

The package contains the 80mm 12V 0.35A 3-pin fan unit with its attached three-wire cable; mounting screws are not included and must be sourced separately.

Which speed range should I expect from the temperature-controlled version of this 8025 fan?

The double-ball bearing fan runs between 1400 and 3800 RPM, automatically adjusting speed based on the onboard temperature probe.

How much airflow and noise will the 0825-12HBTL produce inside my case at full load?

At maximum speed it delivers 35.50 CFM at 21.3 dBA; at minimum speed it provides 15 CFM at 8 dBA.
