Silver 2U rackmount server chassis with eight front 3.5-inch drive bays

Supermicro

Supermicro SYS-620P-TRT 2U barebone server

SKU CH-5B15-ME8NT MPN SYS-620P-TRT

2U rackmount barebone with dual LGA 4189 sockets, 18 DDR4 ECC slots, six PCIe 4.0 slots and eight 3.5-inch hot-swap bays

  • Form Factor2U Rackmount
  • WorkloadGeneral Purpose Server
  • CPU TypeIntel Xeon
  • CPU SocketLGA 4189
  • Installed CPUNo CPU Installed
  • Max Processors2
  • Dual Intel Xeon socket supports scalable compute density
  • 18 DDR4 slots enable up to 4 TB ECC memory
  • Six PCIe 4.0 slots plus M.2 NVMe for flexible expansion
  • 10 Gigabit LAN with dedicated IPMI port for high-speed management
  • Eight hot-swap 3.5-inch bays provide dense storage capacity

2U Dual-Socket Xeon Barebone

The Supermicro SYS-620P-TRT is a 2U rackmount server barebone designed for general-purpose enterprise workloads. It ships without processors or memory, allowing integrators to populate up to two Intel Xeon CPUs in LGA 4189 sockets. The Intel C621A chipset provides the platform foundation for virtualization, data serving and compute-intensive applications. Eighteen DDR4 slots support up to 4TB of ECC registered or load-reduced memory.

Suits Custom Integration, Not Turnkey Use

This barebone suits system builders who need full control over CPU selection, memory capacity and storage configuration. It is not for operators who require a fully assembled, validated server with an operating system pre-installed. Buyers without rack infrastructure or redundant power planning should evaluate tower alternatives. Teams lacking in-house integration resources will find the assembly and validation effort significant.

18 DDR4 Slots Define Maximum Capacity

The eighteen 288-pin DDR4 3200MHz slots set the hard ceiling at 4TB of ECC LRDIMM or RDIMM memory. Populating all channels requires both CPU sockets filled, so single-socket deployments halve the usable slots and total capacity. Memory choice directly determines whether the platform reaches its stated ceiling for virtualization density or in-memory analytics.

Highlights

  • Dual Intel Xeon socket supports scalable compute density
  • 18 DDR4 slots enable up to 4 TB ECC memory
  • Six PCIe 4.0 slots plus M.2 NVMe for flexible expansion
  • 10 Gigabit LAN with dedicated IPMI port for high-speed management
  • Eight hot-swap 3.5-inch bays provide dense storage capacity

Specifications

BrandSUPERMICRO
SeriesSuperServer
ModelSYS-620P-TRT
Form Factor2U Rackmount
WorkloadGeneral Purpose Server
CPU TypeIntel Xeon
CPU SocketLGA 4189
Installed CPUNo CPU Installed
Max Processors2
North BridgeIntel C621A
Memory Slots18 x 288Pin
Installed Memory SizeNo Memory Installed
Max Memory Supported4TB
Memory Type SupportedDDR4 3200MHz ECC LRDIMM/RDIMM
ECC SupportedYes
GPU/VPUASPEED AST2600 BMC
PCI ExpressSlot 1: PCI-E 4.0 x8 LP
Slot 2: PCI-E 4.0 x16 LP
Slot 3: PCI-E 4.0 x16 LP
Slot 4: PCI-E 4.0 x16 LP
Slot 5: PCI-E 4.0 x16 LP
Slot 6: PCI-E 4.0 x8 LP
1 x M.2 NVMe
Max. LAN Speed10 Gigabit
Hot-Swap Bays8 x 3.5" hot-swap fixed optional drive bays
Front USB2 x USB 2.0
COM2 COM Port(s) (1 front; 1 rear)
VGA1
Rear USB4 x USB 3.0
RJ451 decicated IPMI LAN port
Dimensions3.50" x 17.20" x 25.50"
Weight35.50 lbs.
Shipping weight31.30 kg
Package size876 × 678 × 290 mm

Questions about this item

What maintenance will the 8 x 3.5" hot-swap drive bays need later?

The hot-swap bays let you replace failed drives without tools or downtime; keep spare 3.5" drives on hand and monitor SMART data through the BMC.

Which limit appears first when both CPUs run sustained workloads?

The dual LGA 4189 sockets share the C621A chipset and 18 DDR4 3200MHz slots, so memory bandwidth and thermal headroom typically bottleneck before the six PCI-E 4.0 slots saturate.

How much noise and heat does the 2U chassis produce running all day?

The 3.50" x 17.20" x 25.50" chassis uses redundant fans cooled by front-to-rear airflow; expect data-centre noise levels and plan rack cooling for the 35.50 lb system under full load.
