Silver 1U rackmount server chassis, front panel with drive bays and ports

Supermicro

Supermicro SYS-5019C-L 1U barebone server

SKU CH-H4XN-FFP99 MPN SYS-5019C-L

1U rackmount barebone for edge workloads, single LGA 1151 socket up to 95W TDP, 64GB DDR4 ECC, four SATA 600 ports with RAID 0/1/5/10, dual Intel I210-AT LAN and dedicated IPMI port

  • Form Factor1U Rackmount
  • WorkloadEdge Server
  • CPU TypeSingle Socket H4 (LGA 1151), CPU TDP support up to 95W Suppo
  • CPU SocketLGA 1151
  • North BridgeIntel C242
  • Max Memory SupportedUp to 64GB Unbuffered ECC UDIMM Up to DDR4-2666 MHz
  • Compact 1U rackmount form factor saves rack space
  • Single LGA 1151 socket supports up to 95W TDP CPUs
  • Intel C242 chipset enables up to 64GB ECC DDR4 memory
  • Four SATA 600 ports with RAID 0/1/5/10 for flexible storage
  • Dual Intel I210-AT Gigabit LAN plus dedicated IPMI port

1U edge barebone for LGA 1151 CPUs

The Supermicro SYS-5019C-L is a 1U rackmount barebone built around the Intel C242 chipset and a single Socket H4 (LGA 1151). It accepts Xeon E-2100 series processors as well as 8th generation Core i3, Pentium and Celeron CPUs with a thermal design power up to 95W. The platform targets edge deployments that need a compact server chassis with integrated management.

Memory headroom up to 64GB DDR4 ECC

Two UDIMM slots support unbuffered ECC DDR4 at 2666, 2400 or 2133 MHz, giving a maximum capacity of 64GB. That ceiling suits typical edge workloads such as lightweight virtualization or network appliances, but rules out memory-intensive databases or large in-memory caches. Storage connects through four SATA 600 ports with RAID 0, 1, 5 and 10 handled by the chipset.

Single PCIe 3.0 x16 slot and dual GbE

Expansion is limited to one full-size PCI Express 3.0 x16 slot, so only a single add-in card such as a GPU, NIC or storage controller can be fitted. Networking provides two Intel I210-AT Gigabit Ethernet ports plus a dedicated RJ45 for IPMI via the Aspeed AST2500 BMC. The 1U form factor fits standard racks, yet the single expansion slot and 95W CPU ceiling constrain high-density compute or multi-card configurations.

Highlights

  • Compact 1U rackmount form factor saves rack space
  • Single LGA 1151 socket supports up to 95W TDP CPUs
  • Intel C242 chipset enables up to 64GB ECC DDR4 memory
  • Four SATA 600 ports with RAID 0/1/5/10 for flexible storage
  • Dual Intel I210-AT Gigabit LAN plus dedicated IPMI port

Specifications

BrandSUPERMICRO
ModelSYS-5019C-L
Form Factor1U Rackmount
WorkloadEdge Server
CPU TypeSingle Socket H4 (LGA 1151), CPU TDP support up to 95W
Support Intel Xeon Processor E-2100 series, 8th Gen. Intel Core i3 / Pentium / Celeron Processors
CPU SocketLGA 1151
North BridgeIntel C242
Max Memory SupportedUp to 64GB Unbuffered ECC UDIMM
Up to DDR4-2666 MHz
Memory Type SupportedDDR4 2666 / 2400 / 2133 MHz ECC SDRAM
ECC SupportedYes
Serial ATA4 x SATA 600
SATA RAIDRAID 0/1/5/10
GPU/VPUAspeed AST2500 BMC
PCI Express1 x PCI-E 3.0 x16 slot
Number of LANDual LAN with Intel I210-AT
First LANIntel I210-AT
Second LANIntel I210-AT
RJ452 x RJ45 Gigabit Ethernet LAN ports
1 x RJ45 Dedicated IPMI LAN port
FeaturesSingle socket H4 (LGA 1151) supports Intel Xeon processor E-2100, 8th Gen. Intel Core i3 Processors, Intel Celeron, Intel Pentium
Intel C242 chipset
Up to 64GB ECC UDIMM, up to DDR4-2666 MHz; 2 x DIMM slots
1 x PCI-E 3.0 x16 slot
2 x Fixed 3.5" drive bay or 4 x Fixed 2.5" drive bays
M.2 Interface: 1 x PCI-E 3.0 x4
M.2 Form Factor: 2280
M.2 Key: M-Key
2 x GbE LAN ports, 1 x dedicated IPMI LAN
2 x USB 3.1 (rear), 2 x USB 2.0 (rear)
1 x VGA, 2 x COM, 1 x TPM
200W Multi-output power supply, Gold Level Certified
Dimensions1.70" x 17.20" x 9.80"
Shipping weight5.82 kg
Package size650 × 467 × 165 mm

Questions about this item

Will the LGA 1151 socket accept an 8th Gen Intel Core i3 I already own?

Yes, the LGA 1151 socket supports 8th Gen Intel Core i3, Pentium and Celeron processors up to 95 W TDP.

How can I confirm the Aspeed AST2500 BMC is running after first boot?

Connect the dedicated IPMI LAN port, browse to its IP address and the BMC web interface will load if the chip is active.

Does the barebone include DDR4 ECC UDIMMs or must I buy them separately?

Memory is not included; you must purchase up to 64 GB of DDR4 2666/2400/2133 MHz ECC UDIMM modules for the two DIMM slots.
