Silver 2U rackmount chassis with four node sleds and six front 2.5-inch hot-swap drive bays

Supermicro

Supermicro SYS-220BT-HNC8R 2U 4-node barebone server

SKU CH-E9V2-P6XM5 MPN SYS-220BT-HNC8R

A 2U rackmount barebone with four independent nodes, each supporting dual 3rd Gen Xeon Scalable CPUs, 16 DDR4 slots and six 2.5-inch hot-swap drive bays

  • Form Factor2U Rackmount
  • WorkloadAI/ML/HPC
  • CPU Type3rd Gen Intel Xeon Scalable processors
  • CPU SocketLGA 4189
  • Installed CPUNo CPU Installed
  • Max Processors2
  • Four independent compute nodes fit in a single 2U rack space
  • Each node takes two 3rd Gen Intel Xeon Scalable processors for heavy parallel workloads
  • Sixteen DDR4 3200 ECC DIMM slots per system enable up to 6 TB of memory capacity
  • Six front 2.5" hot-swap bays accept NVMe, SATA or SAS drives for flexible all-flash storage
  • Two PCIe 4.0 x16 low-profile slots per node provide high-bandwidth accelerator or networking expansion

Four-node density in 2U

The Supermicro SYS-220BT-HNC8R packs four independent compute nodes into a single 2U rackmount chassis, each node supporting up to two 3rd Gen Intel Xeon Scalable processors on LGA 4189 sockets. It targets AI, ML and HPC workloads that benefit from high core counts and memory bandwidth per unit of rack space. Buyers receive the barebone system only; CPUs, memory and drives must be sourced separately.

Verify power and CPU cooling before ordering

The chassis includes a 2600 W redundant power supply; confirm your rack PDU and circuit can deliver that load. Each node requires a compatible LGA 4189 heatsink or liquid cold plate rated for the chosen Xeon TDP, and these are not included. Memory must be DDR4 3200 ECC RDIMM or LRDIMM modules to reach the 6 TB per-node maximum across the 16 DIMM slots.

Six hot-swap bays and dual PCIe 4.0 slots per node

Each node provides six 2.5-inch hot-swap bays that accept NVMe, SATA or SAS drives, plus two low-profile PCIe 4.0 x16 slots for accelerators or networking cards. Two M.2 slots per node support either NVMe or SATA modules. Rear I/O per node includes one VGA, one COM and two USB 3.0 ports for local management.

Highlights

  • Four independent compute nodes fit in a single 2U rack space
  • Each node takes two 3rd Gen Intel Xeon Scalable processors for heavy parallel workloads
  • Sixteen DDR4 3200 ECC DIMM slots per system enable up to 6 TB of memory capacity
  • Six front 2.5" hot-swap bays accept NVMe, SATA or SAS drives for flexible all-flash storage
  • Two PCIe 4.0 x16 low-profile slots per node provide high-bandwidth accelerator or networking expansion

Specifications

BrandSUPERMICRO
ModelSYS-220BT-HNC8R
Form Factor2U Rackmount
WorkloadAI/ML/HPC
CPU Type3rd Gen Intel Xeon Scalable processors
CPU SocketLGA 4189
Installed CPUNo CPU Installed
Max Processors2
North BridgeIntel C621A
Memory Slots16 x 288Pin
Installed Memory SizeNo Memory Installed
Max Memory Supported6TB
Memory Type SupportedDDR4 3200
ECC SupportedYes
Serial ATA6 x SATA 600
M.22 M.2 NVMe OR 2 M.2 SATA3
PCI ExpressSlot 1: PCI-E 4.0 x16 LP
Slot 2: PCI-E 4.0 x16 LP
Internal Slot: M.2
Hot-Swap Bays6 x 2.5" hot-swap NVMe/SATA/SAS drive bays
COM1
VGA1
Rear USB2 x USB 3.0
Max. Power2600W Redundant
Dimensions3.47" x 17.68" x 28.75"
Weight54.50 lbs.
Shipping weight38.56 kg
Package size1150 × 626 × 248 mm

Questions about this item

What CPUs and memory do I need to add to the four nodes in this 2U barebone?

Each of the four nodes takes up to two 3rd Gen Intel Xeon Scalable processors in LGA 4189 sockets and up to 6 TB of DDR4 3200 ECC RDIMM across 16 DIMM slots per node; no CPUs or memory are installed.

Which M.2 form factor should I select for the internal slot on each node?

The internal M.2 slot on each node accepts either an NVMe or a SATA3 M.2 drive; choose the protocol that matches the drive you plan to install.

What does the 2600 W redundant power supply mean for a fully loaded four-node configuration?

The 2600 W redundant supply powers all four nodes simultaneously, delivering enough headroom for dual CPUs, full memory population, six 2.5-inch hot-swap drives and two PCI-E 4.0 x16 low-profile cards per node.
