Small black metal box with five RJ-45 ports and DIN rail clips

STARTECH

STARTECH IES5102 5-Port Industrial Ethernet Switch network switch

SKU CH-RABG-GSZYD MPN IES5102

A DIN-rail mountable 5-port unmanaged Ethernet switch rated IP30 for industrial environments

  • Switch Typeethernet
  • FormatRail-mountable
  • ProtocolsTCP/IP
  • PowerPoE (RJ-45) Port: No Power Consumption: 2.12 W
  • DimensionsHeight: 4.3" Width: 1" Length: 2.8"
  • WeightWeight (Approximate): 5.30 oz

Class 10/100Base-TX

  • DIN rail mounting suits factory, vehicle and marine installs
  • 5 Fast Ethernet ports connect PCs, printers and peripherals
  • Unmanaged operation adds wired networking with no setup required
  • Low 2.12 W draw keeps energy costs down
  • Meets EN61000-6-2, EN61000-6-4 and IEEE 802.3 standards

Industrial Ethernet Switch for Factory

The IES5102 is a five-port unmanaged switch built for industrial environments. Its DIN-rail mountable format suits factory floors, vehicles and marine installations where standard desktop units cannot be secured. The switch connects PCs, printers and other peripherals at 10/100 Mbps without any configuration required.

10/100 Mbps Fast Ethernet on Five RJ-45 Ports

Every port runs at 10 or 100 Mbps over twisted-pair cabling, delivering the bandwidth needed for basic industrial networking tasks. No PoE, management or uplink ports are present, so the unit only fits applications that need simple, unpowered copper connectivity.

Low Power Draw and Rugged EMI Compliance

The switch consumes 2.12 W in normal operation and meets EN61000-6-2 and EN61000-6-4 for electromagnetic immunity and emissions. An IP30-rated metal housing resists dust and operates across a -10 °C to 45 °C range, while IEEE 802.3az energy-efficient Ethernet reduces idle power further.

Highlights

  • DIN rail mounting suits factory, vehicle and marine installs
  • 5 Fast Ethernet ports connect PCs, printers and peripherals
  • Unmanaged operation adds wired networking with no setup required
  • Low 2.12 W draw keeps energy costs down
  • Meets EN61000-6-2, EN61000-6-4 and IEEE 802.3 standards

Specifications

BrandStarTech.com
ModelIES5102
Switch Typeethernet
FormatRail-mountable
ProtocolsTCP/IP
PowerPoE (RJ-45) Port:
No
Power Consumption:
2.12 W
DimensionsHeight:
4.3"
Width:
1"
Length:
2.8"
WeightWeight (Approximate):
5.30 oz
CertificationCE
FCC
Industry Sandards:
IEEE 802.3
IEEE 802.3u
IEEE 802.3az
IEEE 802.1P
Regulatory Approvals:
EN61000-6-2
EN61000-6-4
EN61000-4-3 (Radiated RFI Standards)
EN61000-4-4 (Burst Standards)
EN61000-4-6 (Induced RFI Standards)
EN61000-4-8 (Magnetic Field Standards)
IEC60068-2-6 Fc (Vibration)
IEC60068-2-27 Ea (Shock)
FeaturesInterfaces/Ports
Total Number of Network Ports:
5
Token Ring Port:
No
LRE Port:
No
Bypass:
No
Modular:
No
Management Port:
No
USB:
No
Stack Port:
No
Number of Network (RJ-45) Ports:
5
Network (RJ-45):
Yes
Port/Expansion Slot Details:
5 x Fast Ethernet Network
Media & Performance
Media Type Supported:
Twisted Pair
Ethernet Technology:
Fast Ethernet
Network Technology:
10/100Base-TX
Network & Communication
Layer Supported:
2
Management & Protocols
Manageable:
No
Reliability
MTBF:
1179133 Hour
Package Contents5-Port Industrial Ethernet Switch - DIN Rail Mountable
1 x Terminal Block
1 x Instruction Manual CD
Shipping weight0.32 kg
Package size196 × 178 × 79 mm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the 10/100 Mbps speed on each of the five ports handle typical industrial sensors and PLCs?

Yes, the switch runs at 10 or 100 Mbps per port, which matches the bandwidth needs of most industrial field devices and legacy automation equipment.

What do the listed IEEE 802.3, 802.3u and 802.3az standards actually limit in daily use?

They cap the switch to Fast Ethernet speeds, enable auto-negotiation, and add energy-efficient idle modes without requiring any configuration.

How does the 4.3" height and 1" width affect DIN-rail installation in a crowded cabinet?

The compact 4.3 by 1 inch footprint lets the unit sit on a standard DIN rail beside other modules while leaving room for wiring and the included terminal block.
