Square D SPDT limit switch, grey industrial housing, side rotary actuator, screw terminals

SQUARE D

SQUARE D SPDT Limit Switch 15A 600V

SKU CH-2B74-PN0BN

Compact SPDT limit switch rated 15A at 600V with screw-clamp terminals and IP20 protection

  • TypeLight Switch
  • Reliable switching with 15 A at 600 V AC/DC
  • Compact body fits tight spaces at 3.47 x 2.38 x 1.38 in
  • SPDT contact form gives one NO and one NC circuit
  • Screw clamp terminals simplify wiring and maintenance
  • IP20 and NEMA 1 rating protects against solid objects

Industrial Limit Switch for Control Circuits

The Square D SPDT limit switch provides a compact body with a rotary actuator mounted on the side. It carries a 15A rating at 600V for both AC and DC circuits and uses a 1NC/1NO contact form. The NEMA 1 enclosure and IP20 rating suit indoor industrial panels.

Verify Voltage and Mounting Before Purchase

Confirm that your control circuit operates at or below 600V AC or DC and that the 15A contact rating meets the load requirement. The switch body measures 3.47 in high, 2.38 in wide and 1.38 in deep, so check available panel space. Screw clamp terminals accept standard wire ferrules or stripped conductors.

Integrates Into Safety and Position Sensing Loops

The side rotary actuator accepts a lever or cam to detect mechanical position without a supplied lever. Wiring to the screw clamp terminals frees DIN rail space because the switch mounts directly to the sub-panel. The IP20 rating means no additional sealing is needed inside a rated enclosure.

Highlights

  • Reliable switching with 15 A at 600 V AC/DC
  • Compact body fits tight spaces at 3.47 x 2.38 x 1.38 in
  • SPDT contact form gives one NO and one NC circuit
  • Screw clamp terminals simplify wiring and maintenance
  • IP20 and NEMA 1 rating protects against solid objects

Specifications

BrandSquare D
TypeLight Switch

Questions about this item

What is included with the limit switch and what must be purchased separately?

The switch body is supplied without a lever actuator; a compatible rotary lever must be bought separately for operation.

Which version should I choose for a 600 V control circuit?

This SPDT model is rated 15 A at 600 V AC and DC, matching the voltage and current shown in the specifications.

How does the 15 A 600 V rating apply when the switch is installed in a panel?

The screw-clamp terminals accept wiring for 15 A loads at 600 V, the NEMA 1 and IP20 ratings mean the body is for indoor use only.
