Compact grey pressure switch with single port and adjustment spring visible

SQUARE D

SQUARE D 9013FR Pressure Switch 10-5PSI DPST 10A

SKU CH-GTFJ-9379R

Water-pump pressure switch with 10/5 psi factory settings and DPST contacts rated 10 A at 120 or 240 V

  • TypeLight Switch
  • Reliable water-pump control with factory-set 10/5 psi cut-in/out
  • DPST contacts handle up to 10 A at 120 V or 240 V
  • Single 1/4 in FNPS port simplifies plumbing connections
  • Wide adjustable differential of 6 to 20 psi suits varied pressure needs
  • Operates from –22 °F to 257 °F for harsh environments

Pressure switch for water-pump control

The Square D 9013FR is a DPST pressure switch rated 10 A for single-phase motors up to 1 hp at 120 V or 240 V and three-phase motors up to 1 hp at 240 V. It opens on rising pressure and closes on falling pressure with a factory setting of 10 psi on and 5 psi off. The adjustable differential spans 6 to 20 psi within an overall range of 4 to 45 psi.

Check voltage, phase and pressure requirements

Verify that the motor voltage and phase match the 120 V or 240 V single-phase and 240 V three-phase ratings listed. Confirm the system’s normal operating pressure falls inside the 4 to 45 psi range and that the desired cut-in and cut-out points can be achieved with the 6 to 20 psi differential. Ensure the 10 A contact rating covers the motor’s full-load current.

NEMA 1 enclosure with 1/4 in FNPS port

The NEMA 1 enclosure is intended for indoor, non-hazardous locations and operates from -22 °F to 257 °F. A single 1/4 in FNPS port connects directly to the pump or tank fitting without extra adapters. DPST contacts break both lines for positive isolation. The switch is not suitable for outdoor exposure or for controlling loads beyond the stated horsepower and current limits.

Highlights

  • Reliable water-pump control with factory-set 10/5 psi cut-in/out
  • DPST contacts handle up to 10 A at 120 V or 240 V
  • Single 1/4 in FNPS port simplifies plumbing connections
  • Wide adjustable differential of 6 to 20 psi suits varied pressure needs
  • Operates from –22 °F to 257 °F for harsh environments

Specifications

BrandSquare D
TypeLight Switch

Questions about this item

Does the 9013FR pressure switch come with fittings or do I need to supply the 1/4 in FNPS connection myself?

The switch has a single 1/4 in FNPS port; no fittings are included so you must provide the mating connector and tubing.

Should I choose the 10/5 psi factory setting or adjust the 6-20 psi differential for my pump?

The unit ships set to cut-in at 10 psi and cut-out at 5 psi; the differential can be adjusted anywhere between 6 and 20 psi to match your system pressure range of 4-45 psi.

Will the DPST contacts handle my 1 hp motor at 240 V single-phase?

Yes, the DPST contacts are rated for 1 hp at 120 V or 240 V single-phase and also 1 hp at 240 V three-phase within the -22 to 257 °F operating range.
