White desktop firewall appliance with front antennae and multiple network ports

SonicWall

SonicWall TZ270W firewall appliance 03-SSC-3002

SKU CH-B7X4-PE0VX MPN 03-SSC-3002

A wireless desktop firewall with 8 Gigabit ports, dual-band Wi-Fi and three years of advanced threat protection for up to 1,000 users

  • TypeWireless
  • Form FactorDesktop
  • StandardsTCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHC
  • ProtocolsBGP, OSPF, RIPv1/v2, static routes, policy-based routing
  • SecurityDeep Packet Inspection services: Gateway Anti-Virus, Anti-Sp
  • Encryption StandardDES, 3DES, AES

Hardware TZ 270W

Option Secure Upgrade Plus (Appliance + 3Y APSS) +1Y CSE

  • Industry-validated security effectiveness for lean branches
  • 8×1 GbE ports plus 2 USB 3.0 interfaces
  • 750,000 simultaneous sessions support 1,000+ users
  • 4 GHz/5 GHz wireless with FIPS 140-2 Level 2 certification
  • 84 W max power draw from 36 W external supply

Compact Wireless Firewall for Small Sites

The SonicWall TZ270W is a desktop-form-factor security appliance built for home offices and lean branches. It combines a next-generation firewall with integrated dual-band wireless on 2.4 GHz and 5 GHz frequencies. The bundle includes three years of Advanced Protection Security Suite and one year of Cloud Secure Edge service. It supports up to 1,000 concurrent users and 750,000 simultaneous sessions.

Throughput Limits on Gigabit Interfaces

Eight 1 GbE ports and two USB 3.0 ports provide wired and peripheral connectivity. Firewall inspection throughput reaches 2 Gbps, while threat prevention, anti-malware and SSL-VPN throughput are capped at 750 Mbps. Application inspection and IPS throughput each top out at 1 Gbps. These ceilings define the practical maximum for protected traffic on the appliance.

Replaces Standalone Router

The TZ270W consolidates routing, switching, wireless access and deep-packet inspection in one unit. It removes the need to manage a discrete access point and a separate UTM appliance. The jump is worthwhile when a site wants single-pane-of-glass management, zero-touch deployment and SD-WAN readiness without adding rack-mounted hardware.

Highlights

  • Industry-validated security effectiveness for lean branches
  • 8×1 GbE ports plus 2 USB 3.0 interfaces
  • 750,000 simultaneous sessions support 1,000+ users
  • 4 GHz/5 GHz wireless with FIPS 140-2 Level 2 certification
  • 84 W max power draw from 36 W external supply

Specifications

BrandSONICWALL
SeriesTZ270 Series
ModelTZ270W - 3& Free (3Y APSS + 1Y CSE)
Part Number03-SSC-3002
TypeWireless
Form FactorDesktop
StandardsTCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
ProtocolsBGP, OSPF, RIPv1/v2, static routes, policy-based routing
SecurityDeep Packet Inspection services: Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
Content Filtering Service (CFS): HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
Comprehensive Anti-Spam Service
Application Visualization
Application Control
Capture Advanced Threat Protection
Encryption StandardDES, 3DES, AES
Frequency Band2.4 GHz/5 GHz
Ports8x1GbE, 2 USB 3.0
Simultaneous Sessions750000
Maximum Users1000+
VPNFirewall / VPN Performance
Firewall inspection throughput: 2 Gbps
Threat prevention throughput: 750 Mbps
Application inspection throughput: 1 Gbps
IPS throughput: 1 Gbps
Anti-malware inspection throughput: 750 Mbps
TLS/SSL inspection and decryption throughput (DPI SSL): 300 Mbps
IPSec VPN throughput: 750 Mbps
Connections per second: 6,000
Maximum connections (SPI): 750,000
Maximum connections (DPI): 150,000
Maximum connections (DPI SSL): 25,000
VPN
Site-to-site VPN tunnels 50
IPSec VPN clients (maximum) 5 (200)
SSL VPN licenses (maximum) 1 (50)
Encryption/authentication: DES, 3DES, A
OS SupportWindows, Mac, Linux
CertificationsFIPS 140-2 Level 2 (with Suite B), IPv6/USGv6, ICSA Network Firewall, ICSA Firewall Enterprise, ISCA
Network Antivirus / AntiMalware
ComplianceFCC Class B, FCC RF ICES Class B, IC RF CE (R&TTE, EMC, LVD, RoHS), RCM, VCCI Class B, MIC/TELEC, UL, cUL, CB, Mexico CoC by UL, WEEE, REACH, ANATEL
Power Input36W external
Max Power Consumption16.84W
FeaturesIntegrated Wireless
Standards: 802.11a/b/g/n/ac Wave 2, WEP, WPA, WPA2, 802.11i, TKIP, PSK,02.1x, EAP-PEAP, EAP-TTLS
Frequency bands: 802.11a: 5.180-5.825 GHz; 802.11b/g: 2.412-2.472 GHz; 802.11n: 2.412-2.472 GHz, 5.180-5.825 GHz; 802.11ac: 5.180-5.825 GHz
Operating channels
802.11a: 12
802.11b/g: 1-11
802.11n (2.4 GHz): 1-11
802.11n (5 GHz): 36-48/149-165
802.11ac: 36-48/149-165
Transmit output power: Based on the regulatory domain specified by the system administrator
Transmit power control
Data rates supported: 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps per channel; 802.11b: 1, 2,
Dimensions3.5x13.5x19 (cm)
1.8x5.3x7.5 (in)
Weight0.85 kg / 1.87 lbs
Shipping weight1.41 kg
Package size229 × 229 × 76 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Which TZ270W configuration does part number 03-SSC-3002 represent?

This SKU bundles the TZ270W Gen 7 wireless firewall with three years of Advanced Protection Security Suite and one year of Cloud Secure Edge, delivered as a desktop unit with 8x1GbE ports and dual-band Wi-Fi.

What does the 2 Gbps firewall inspection throughput mean for daily traffic?

It is the maximum rate at which the appliance can inspect packets with the firewall engine enabled; real-world throughput will be lower once threat prevention, IPS or anti-malware services are active.

What encryption standards are supported on the VPN interfaces?

The VPN engine negotiates DES, 3DES or AES encryption for IPSec tunnels, with the actual cipher chosen during peer negotiation.
