White desktop firewall appliance with integrated wireless antennas, front LED panel and rear port array

SonicWall

SonicWall TZ570W Wireless Firewall Appliance 02-SSC-2835

SKU CH-44YB-8N6Y4 MPN 02-SSC-2835

Desktop wireless firewall with 8x1GbE and 2x5GbE ports, integrated 802.11ac Wave 2 Wi-Fi, DPI-SSL inspection, and up to 1,250,000 simultaneous sessions for 2,500 users

  • TypeWireless
  • Form FactorDesktop
  • StandardsTCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHC
  • ProtocolsBGP, OSPF, RIPv1/v2, static routes, policy-based routing
  • SecuritySecurity Services Deep Packet Inspection services: Gateway A
  • Ports8x1GbE, 2x5GbE, 2 USB 3.0

Hardware TZ 570W

Option Hardware Only

  • Enterprise-grade security with Deep Packet Inspection and SSL decryption
  • Integrated 802.11ac Wave 2 wireless for secure Wi-Fi access
  • 8×1GbE plus 2×5GbE ports for high-throughput connectivity
  • Supports 200 site-to-site VPN tunnels and 500 IPSec clients
  • FIPS 140-2 Level 2 validated with Suite B cryptography

SonicWall TZ570W Wireless Firewall Appliance

The SonicWall TZ570W is a desktop network security appliance that combines firewall, VPN and wireless access in one unit. It runs SonicWall Security Services including Deep Packet Inspection for intrusion prevention, anti-virus, anti-spyware and SSL inspection. The device supports up to 2,500 users and 1,250,000 simultaneous sessions for small to mid-sized organisations.

Suits small branches needing integrated Wi-Fi

This model fits sites that want a single box for secure wireless access, site-to-site VPN tunnels and cloud-managed SD-Branch deployment. It is not suited for buyers who need higher VPN client capacity, more multi-gigabit ports or rack-mount form factor.

200 site-to-site VPN tunnels

The appliance provides 200 site-to-site VPN tunnels, 10 IPSec VPN clients expandable to 500, and 2 SSL VPN licenses expandable to 200. Connectivity includes eight 1GbE ports, two 5GbE SFP+ ports and two USB 3.0 interfaces for WAN diversity and local storage.

Highlights

  • Enterprise-grade security with Deep Packet Inspection and SSL decryption
  • Integrated 802.11ac Wave 2 wireless for secure Wi-Fi access
  • 8×1GbE plus 2×5GbE ports for high-throughput connectivity
  • Supports 200 site-to-site VPN tunnels and 500 IPSec clients
  • FIPS 140-2 Level 2 validated with Suite B cryptography

Specifications

BrandSONICWALL
SeriesTZ 570W
ModelTZ 570W
Part Number02-SSC-2835
TypeWireless
Form FactorDesktop
StandardsTCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
ProtocolsBGP, OSPF, RIPv1/v2, static routes, policy-based routing
SecuritySecurity Services
Deep Packet Inspection services: Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
Content Filtering Service (CFS): HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
Comprehensive Anti-Spam Service
Application Visualization
Application Control
Capture Advanced Threat Protection
Ports8x1GbE, 2x5GbE, 2 USB 3.0
Simultaneous Sessions1250000
Maximum Users2500
VPNSite-to-site VPN tunnels: 200
IPSec VPN clients (maximum:) 10 (500)
SSL VPN licenses (maximum): 2 (200)
Encryption/authentication: DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
Key exchange: Diffie Hellman Groups 1, 2, 5, 14v
Route-based VPN: RIP, OSPF, BGP
Certificate support: Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to- SonicWall VPN, SCEP
VPN features: Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
Global VPN client platforms supported: Microsoft®, Windows 10
NetExtender: M
CertificationsFIPS 140-2 Level 2 (with Suite B), IPv6/USGv6, ICSA Network Firewall, ICSA Firewall Enterprise, ISCA Network Antivirus / AntiMalware
ComplianceFCC Class B, FCC P15C, FCC P15E, ICES Class B, ISED/ IC, CE (RED, RoHS), C-Tick, VCCI Class B, Japan Wireless, UL/cUL, CB, Mexico DGN notice by UL, WEEE, REACH, BSMI, NCC (TW) KCC/MSIP, SRRC, ANATEL
Power Input100-240 VAC,
50-60 Hz
Max Power Consumption15.3W
FeaturesIntegrated Wireless
Standards: 802.11a/b/g/n/ac Wave 2, WEP, WPA, WPA2, 802.11i, TKIP, PSK,02.1x, EAP-PEAP, EAP-TTLS
Frequency bands: 802.11a: 5.180-5.825 GHz; 802.11b/g: 2.412-2.472 GHz; 802.11n: 2.412-2.472 GHz, 5.180-5.825 GHz; 802.11ac: 5.180-5.825 GHz
Operating channels
802.11a: 12
802.11b/g: 1-11
802.11n (2.4 GHz): 1-11
802.11n (5 GHz): 36-48/149-165
802.11ac: 36-48/149-165
Transmit output power: Based on the regulatory domain specified by the system administrator
Transmit power control
Data rates supported: 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps per channel; 802.11b: 1, 2,
Dimensions3.5x15x22.5 (cm)
1.38x5.91x8.85 in
Weight0.99 kg / 2.18 lbs
Shipping weight2.27 kg
Package size451 × 267 × 76 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I choose the appliance-only TZ570W or a bundle with security licences?

The 02-SSC-2835 is the appliance only; licences for Gateway Anti-Virus, IPS, CFS, Anti-Spam and Capture ATP are sold separately and can be added later.

What does the 1 250 000 simultaneous-session figure mean for daily throughput?

It is the maximum concurrent TCP/UDP flows the box can track; actual throughput depends on enabled DPI services and traffic mix.

How do the 2.5 GbE SFP+ ports limit real-world WAN speed?

The two SFP+ cages accept 2.5 GbE transceivers, capping each WAN link at 2.5 Gbit/s full duplex.
