Silver rack-mount security appliance with front ports and ventilation slots

SonicWall

SonicWall NSA 2700 firewall appliance 02-SSC-8199

SKU CH-BV2F-KCQXP MPN 02-SSC-8199

Mid-range firewall appliance for up to 250 users with 16 Gigabit Ethernet ports, three 10 Gb SFP+ ports and 2.1 Gbps IPsec VPN throughput

  • Firewall TypeFirewalls / Security Appliances
  • TypeWired
  • StandardIEEE 802.3
  • Simultaneous SessionsNew Sessions Per Second: 21000
  • Ports16x1GbE, 3x10G SFP+, 2 USB 3.0, 1 Console, 1 Mgmt. port
  • VPNVPN IPSec Throughput: 2.1 Gbps

Hardware NSa 2700

Option Secure Upgrade Plus (Appliance + 2Y APSS)

  • Handles 21000 new sessions per second for high throughput
  • 16 Gigabit Ethernet and 3 10G SFP+ ports for dense connectivity
  • 1 Gbps IPSec VPN throughput secures remote access
  • Includes 2-year Advanced Protection Security Suite for comprehensive defence
  • Compact 1U rack form factor at 16.9 x 12.8 x 1.8 inches

Mid-range firewall for 250-plus users

The SonicWall NSA 2700 is a wired network security appliance built for organisations with 250 users or more. It combines intrusion prevention, application control and content filtering in a single rack-mount chassis. The bundled Secure Upgrade Plus suite adds gateway anti-virus, anti-spam and 24×7 support for two years. It is not suited to small offices that need only basic NAT or web filtering.

IEEE 802.3 wired throughput limits

The appliance processes 21,000 new sessions per second and delivers 2.1 Gbps of IPsec VPN throughput across its 16 Gigabit Ethernet and three 10 GbE SFP+ ports. Aggregate inspection capacity is bounded by the 21.5 W power envelope and the 100–240 VAC supply. Environments that require higher session rates or multi-gigabit VPN aggregates will exceed the practical ceiling of this platform.

Rack-mount build with mixed copper and fibre

A 1U profile measuring 16.9 by 12.8 by 1.8 inches fits standard 19-inch racks and provides front-access copper ports alongside fibre uplinks. Two USB 3.0 ports, a console port and a dedicated management port simplify local staging and out-of-band access. The lack of PoE support means attached access points or phones need separate injectors or switches.

Highlights

  • Handles 21000 new sessions per second for high throughput
  • 16 Gigabit Ethernet and 3 10G SFP+ ports for dense connectivity
  • 1 Gbps IPSec VPN throughput secures remote access
  • Includes 2-year Advanced Protection Security Suite for comprehensive defence
  • Compact 1U rack form factor at 16.9 x 12.8 x 1.8 inches

Specifications

BrandSonicWall
ModelNSa 2700
Part Number02-SSC-8199
Firewall TypeFirewalls / Security Appliances
TypeWired
StandardIEEE 802.3
Simultaneous SessionsNew Sessions Per Second: 21000
Ports16x1GbE, 3x10G SFP+, 2 USB 3.0, 1 Console, 1 Mgmt. port
VPNVPN IPSec Throughput: 2.1 Gbps
Power InputPoE Power Consumption: None
Power / Device Type: Power Supply
Max Power Consumption: 21.5 Watt
Power / Voltage Required: 100-240 VAC, 50-60 Hz
FeaturesBlocks More Attacks With RTDMI; Secure Remote Workers; Secure SD-WAN Technology; Built-in Wireless Controller; Low Total Cost of Ownership; Cloud-based & On-Premises Centralized Management; High Performance and Port Density
DimensionsWidth: 16.9 Inch
Depth: 12.8 Inch
Height: 1.8 Inch
Shipping weight10.43 kg
Package size582 × 478 × 180 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Which capacity of the included Secure Upgrade Plus subscription should I choose?

The appliance ships with a fixed 2-year Advanced Protection Service Suite subscription; there are no alternative capacity tiers to select.

What does the 2.1 Gbps IPsec VPN throughput figure mean when the unit is under load?

It represents the maximum encrypted VPN traffic the NSA 2700 can process through its IPsec engine under ideal conditions.

How does the IEEE 802.3 wired standard limit the 10G SFP+ ports in practice?

The ports operate at up to 10 Gbps full-duplex over compatible SFP+ transceivers and cabling defined by the 802.3 standard.
