Green circuit board with two M.2 slots and gold PCIe edge connector

SMUGDESK

SMUGDESK PH39 Dual M.2 NVMe SATA PCIe Adapter

SKU CH-D569-6THN1

Adds one NVMe and one SATA M.2 SSD to a PCIe slot, delivering 32Gbps and 6Gbps respectively

  • Dual M.2 slots for NVMe and SATA SSDs simultaneously
  • Up to 32Gbps NVMe bandwidth for fast storage performance
  • Works with PCIe x4, x8, x16 slots on desktops and servers
  • Driver-free plug-and-play install for quick RAID or backup setup
  • Supports M-Key, B-Key and B+M-Key M.2 drives for mixed-protocol expansion

Dual NVMe and SATA expansion

The SMUGDESK PH39 adapter adds one NVMe MKey SSD running at 32Gbps and one NGFF SATA SSD at 6Gbps to a single PCIe slot. It suits builders who want mixed-protocol storage on a desktop, workstation or small server without occupying multiple expansion slots.

Check slot and drive keys

Your motherboard must provide a free PCIe X4, X8 or X16 slot and the M.2 drives must match MKey for NVMe or BKey/B+MKey for SATA. The card does not support NVMe on BKey drives or SATA on MKey drives, so verify each SSD keying before ordering.

Driver-free RAID readiness

The plug-and-play design needs no extra software, letting the operating system see both drives immediately for multidisk arrays or backup sets. No bundled utilities or management tools are included, so RAID configuration relies on your platform firmware or OS utilities.

Highlights

  • Dual M.2 slots for NVMe and SATA SSDs simultaneously
  • Up to 32Gbps NVMe bandwidth for fast storage performance
  • Works with PCIe x4, x8, x16 slots on desktops and servers
  • Driver-free plug-and-play install for quick RAID or backup setup
  • Supports M-Key, B-Key and B+M-Key M.2 drives for mixed-protocol expansion

Specifications

No published specifications for this item yet.

Questions about this item

Does the PH39 include any M.2 screws or thermal pads, or must they be sourced separately?

The adapter board is supplied alone; mounting screws and thermal pads are not included and must be purchased separately.

Should I choose an MKey NVMe drive or a BKey SATA drive for the second slot if I want the highest throughput?

Use an MKey NVMe SSD in the first slot for up to 32Gbps and a BKey or B+MKey SATA SSD in the second slot for 6Gbps.

Will the 32Gbps NVMe link run at full speed when the card is installed in a PCIe X4 slot?

Yes, the X4 electrical connection provides the full 32Gbps bandwidth for the NVMe drive.
