Pair of black ABS CCTV video baluns with BNC and terminal block connectors, short pigtail cables

Ruth's sister

Ruth's sister CCTV BNC to CAT5e Video Power Balun Pair

SKU CH-XATX-W4XXT

A passive pair extends CCTV video and power over CAT5e up to 320 metres with built-in surge protection

  • Transmit 720P TVI video up to 250 metres over CAT5e
  • Extend 720P AHD signals to 320 metres without active power
  • Built-in 4KV surge and 8KV ESD protection safeguards equipment
  • ABS housing with power indicator shows real-time supply status
  • Passive design operates from DC to 60MHz with 60dB noise immunity

CCTV BNC to CAT5e balun pair

This passive transceiver pair converts coaxial BNC video and power signals for transmission over standard CAT5e cabling. It supports HD-CVI, HD-TVI and HD-AHD cameras simultaneously, making it suitable for mixed analogue-HD surveillance installations. No external power supply is required for operation. The compact ABS housing includes a power indicator for real-time status monitoring.

60 MHz bandwidth and 250 m reach

Frequency response extends from DC to 60 MHz with typical attenuation of 0.5 dB, ensuring clean video transport for 720P and 1080P TVI cameras up to 250 metres. AHD cameras at 720P can reach 320 metres over the same cable. Common-mode rejection of 60 dB plus 4 kV surge and 8 kV ESD protection maintain signal integrity in electrically noisy environments.

Male BNC and press-fit terminals

Each unit provides a male BNC connector at 75 ohms and press-fit terminal blocks at 100 ohms for direct wire attachment without soldering. The 11.6 cm pigtail allows flexible routing inside junction boxes or camera housings. Indoor-only construction limits deployment to dry, temperature-controlled areas between -10 °C and +70 °C.

Highlights

  • Transmit 720P TVI video up to 250 metres over CAT5e
  • Extend 720P AHD signals to 320 metres without active power
  • Built-in 4KV surge and 8KV ESD protection safeguards equipment
  • ABS housing with power indicator shows real-time supply status
  • Passive design operates from DC to 60MHz with 60dB noise immunity

Specifications

No published specifications for this item yet.

Questions about this item

What distance can 1080P TVI video travel over CAT5e with these baluns?

The 1080P TVI signal reaches 250 metres over CAT5e using this passive pair.

What bandwidth does the DC to 60MHz rating cover for analogue HD formats?

The 60MHz frequency response supports 720P and 1080P CVI, TVI and AHD video without active power.

What connectors and cable length are on each transceiver for installation?

Each unit has a male BNC, press-fit terminal blocks and an 11.6 cm pigtail for the RJ45 link.
