Silver rack-mount network switch with 48 RJ45 ports and two QSFP+ uplinks

RUCKUS WIRELESS

RUCKUS WIRELESS ICX7550-48P-E2-R3 48-port PoE+ network switch

SKU CH-G7PY-15TW2 MPN ICX7550-48P-E2-R3

A 48-port gigabit PoE+ switch with dual 40 Gbps QSFP+ uplinks, dual power supplies and MACsec encryption, optimised for Wi-Fi 6 deployments

  • Primary PortsInterfaces: 48-port 10/100/1000 Mbps 802.3at POE+ with 2-por
  • Buffer MemoryRAM / Total Installed Size: 4 GB Flash Memory / Installed Si
  • PowerPower / Device Type: Power Supply Power / Installed Qty: 2 P
  • TemperatureMin Operating Temperature: 0 C Max Operating Temperature: 45

Version 3 Year Support

  • 48 ports power Wi-Fi 6 access points with 802.3at PoE+
  • Dual 40 Gbps QSFP+ uplinks give 100 GbE stacking headroom
  • 1200 W dual supply runs 90 W 802.3bt on every port
  • MACsec 128-bit and 256-bit encryption secures data in flight
  • Operating range 0 °C to 45 °C fits standard rack environments

48-port PoE+ stackable switch

The Ruckus ICX 7550 provides 48 ports of 10/100/1000 Mbps connectivity with 802.3at PoE+ support. Two 40 Gbps QSFP+ ports handle uplink and stacking duties. A modular slot allows additional interface options. Dual power supplies deliver 1200 Watt total capacity for demanding deployments.

Suits Wi-Fi 6 campus rollouts needing high-density

Organisations deploying Wi-Fi 6 access points and multigigabit endpoints will benefit from up to 90 W per port and advanced Layer 3 routing. MACsec 128-bit and 256-bit encryption addresses strict data-privacy requirements. Sites requiring only basic Layer 2 switching or fewer than 48 powered ports may find the feature set excessive.

Fits 1U rack builds with 180-240 V supply

The switch operates from 0 °C to 45 °C and stores from -40 °C to 70 °C, so standard server-room cooling is sufficient. Dual hot-swap power supplies free up resilience planning, while the modular uplink slot keeps aggregation options open. Ensure rack power distribution matches the 180-240 V input range.

Highlights

  • 48 ports power Wi-Fi 6 access points with 802.3at PoE+
  • Dual 40 Gbps QSFP+ uplinks give 100 GbE stacking headroom
  • 1200 W dual supply runs 90 W 802.3bt on every port
  • MACsec 128-bit and 256-bit encryption secures data in flight
  • Operating range 0 °C to 45 °C fits standard rack environments

Specifications

BrandRuckus
Part NumberICX7550-48P-E2-R3
Primary PortsInterfaces: 48-port 10/100/1000 Mbps 802.3at POE+ with 2-ports 40 Gbps Uplink/Stack QSFP+
10/100/1000BASE-T Ports: 48
Buffer MemoryRAM / Total Installed Size: 4 GB
Flash Memory / Installed Size: 4 GB
PowerPower / Device Type: Power Supply
Power / Installed Qty: 2
Power / Provided (W): 1200 Watt
Max Power Consumption: 1131.6 Watt
Power / Voltage Required: 180-240V
TemperatureMin Operating Temperature: 0 C
Max Operating Temperature: 45 C
Min Storage Temperature: -40 C
Max Storage Temperature: 70 C
Shipping weight11.70 kg
Package size440 × 406 × 44 mm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What type of power circuit do I need for the dual 1200 W supplies?

Each supply requires an 180-240 V AC circuit; plan two dedicated feeds for full redundancy.

Will my existing 1 Gb SFP+ modules work in the 40 Gbps QSFP+ uplink ports?

The QSFP+ ports accept 40 GbE or 100 GbE optics; 1 Gb SFP+ modules are not compatible with these cages.

How can I confirm the switch is forwarding at line rate after installation?

Check the port counters for zero CRC errors and verify MACsec 128-bit or 256-bit encryption status on secured links.
