Rectangular black network video recorder with front USB port and rear HDMI VGA Ethernet audio connections

Reolink

Reolink NVS36 36CH NVR 48TB 3 SATA 12MP

SKU CH-8PZZ-D6G0C

A 36-channel network video recorder supporting up to 12MP IP cameras with three SATA bays for 48TB total storage

  • Channel36
  • Supported ProtocolsHTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTMP, SMTP, SSL/TLS, DNS
  • Compression FormatH.265, H.264
  • Recording TypeVideo Recorder
  • Max Capacity48TB
  • Power SupplyDC 12V/5.4A
  • Manage 36 cameras simultaneously with Reolink PoE and WiFi models
  • Store up to 48TB across three SATA bays for 20 days of 24/7 recording
  • Hear and speak through cameras using built-in audio ports and two-way talk
  • View live or playback at resolutions up to 4608x1728 with H.265 compression
  • Connect up to four PoE switches via LAN ports for extended coverage and zero latency

36-Channel NVR for Reolink IP Cameras

This 36-channel network video recorder manages up to 36 Reolink PoE and Wi-Fi cameras simultaneously. It accepts IP camera inputs up to 12MP resolution and records in H.265 or H.264 formats. The unit is designed for business-grade surveillance systems requiring centralised management of multiple camera feeds.

Thermals Noise and Power Draw

The recorder operates between -10°C and 45°C with humidity tolerance from 10% to 90%. Power consumption stays below 10W from the included DC 12V/5.4A supply. With no PoE ports on the NVR itself, the unit runs silently without active cooling noise in normal office or server-room environments.

Three SATA Bays and Alarm Integration

Three internal SATA ports each accept up to 16TB drives for a total 48TB capacity, providing roughly 20 days of 24/7 recording at 6Mbps per channel across 36 cameras. Video output uses one HDMI and one VGA port. Eight alarm inputs and four alarm outputs plus RCA audio in/out support two-way talk and external sensor integration. Four dedicated camera RJ-45 ports and one LAN/WAN port connect to PoE switches for system expansion.

Highlights

  • Manage 36 cameras simultaneously with Reolink PoE and WiFi models
  • Store up to 48TB across three SATA bays for 20 days of 24/7 recording
  • Hear and speak through cameras using built-in audio ports and two-way talk
  • View live or playback at resolutions up to 4608x1728 with H.265 compression
  • Connect up to four PoE switches via LAN ports for extended coverage and zero latency

Specifications

BrandReolink
SeriesNetwork Video Recorder
Model36CH Network Video Recorder: NVS36
Part NumberPN12M-36
Channel36
Supported ProtocolsHTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTMP, SMTP, SSL/TLS, DNS, DDNS, NTP
Compression FormatH.265, H.264
Recording TypeVideo Recorder
Max Capacity48TB
Power SupplyDC 12V/5.4A
Temperature-10°C ~+45°C (14°F~113°F)
Humidity10%~90%

Questions about this item

How do I install the Reolink NVS36 and what is the common mistake with the LAN ports?

Connect cameras to a PoE switch, then link up to four switches to the four RJ-45 camera ports; the separate LAN/WAN port is for the router, not cameras.

What maintenance will the three SATA drive bays need over time?

Each bay accepts up to 16 TB drives for a 48 TB total; plan to replace drives after their rated workload or if SMART errors appear.

What limit appears first during continuous 36-channel recording?

At 6 Mbps per channel the 48 TB array fills in roughly 20 days, so storage capacity is the first constraint.
