Compact fanless aluminium box with four 2.5G RJ45 ports and two 10G SFP+ cages

partaker

partaker H1 i5-1235U 16GB 256GB firewall appliance

SKU CH-AMSF-2GGXF

Fanless 12th Gen Intel Core i5 firewall appliance with four 2.5 GbE and two 10 GbE SFP+ ports, 16 GB DDR5 and 256 GB NVMe storage

  • TypeWired
  • LAN Ports4 x RJ-45

H1 Fanless I5 1235U 16GB RAM / 256GB SSD

  • 12th Gen Intel i5-1235U with 10 cores and 12 threads up to 4.4 GHz for responsive firewall throughput
  • Fanless aluminium chassis measuring 170 by 140 by 58 mm runs silently in noise-sensitive environments
  • Four Intel 2.5GbE ports plus dual 10GbE SFP+ links deliver high-density wired connectivity
  • Triple display outputs via HD, DP and Type-C support 4096 by 2160 at 60 Hz for multi-monitor monitoring
  • Three M.2 slots for NVMe, Wi-Fi and 4G/5G plus external SIM slot enable flexible expansion

Fanless i5-1235U firewall appliance

The Partaker H1 is a new fanless network security device built around an Intel Core i5-1235U processor with 10 cores and 12 threads reaching 4.4 GHz. It ships with 16 GB of DDR5 memory and a 256 GB NVMe SSD. The aluminium chassis measures 170 by 140 by 58 mm and operates silently without moving parts.

Four 2.5G LAN plus dual 10G SFP+

This unit replaces older 1 GbE appliances by providing four Intel i226 2.5G RJ-45 ports and two Intel 82599 10G SFP+ interfaces. The jump is worth it when aggregated throughput or fibre uplinks are required for multi-gigabit WAN links, high-density VLAN segmentation or storage-area-network traffic. LAN1 adds Intel vPro manageability for out-of-band control.

Suits silent edge and industrial deployments

The fanless design, wide-temperature tolerance, TPM 2.0 and watchdog timer suit industrial control, robotics, IoT gateways and edge-computing sites where noise or dust rules out active cooling. Buyers needing more than 64 GB of memory, additional 2.5-inch drive bays or built-in Wi-Fi radios should look at other platforms.

Highlights

  • 12th Gen Intel i5-1235U with 10 cores and 12 threads up to 4.4 GHz for responsive firewall throughput
  • Fanless aluminium chassis measuring 170 by 140 by 58 mm runs silently in noise-sensitive environments
  • Four Intel 2.5GbE ports plus dual 10GbE SFP+ links deliver high-density wired connectivity
  • Triple display outputs via HD, DP and Type-C support 4096 by 2160 at 60 Hz for multi-monitor monitoring
  • Three M.2 slots for NVMe, Wi-Fi and 4G/5G plus external SIM slot enable flexible expansion

Specifications

TypeWired
LAN Ports4 x RJ-45

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What are the exact chassis dimensions so I can confirm it fits my DIN-rail bracket?

The fanless aluminum chassis measures 170 mm wide, 140 mm deep and 58 mm high, so verify those clearances against your bracket before mounting.

Which M.2 slot should I populate first when adding a second NVMe drive?

Use the M.2 2280 M-key slot wired for PCIe 4.0 x4; it is the only slot that supports NVMe, while the 2230 E-key and 2242/3052 B-key slots serve Wi-Fi and cellular modules.

How do I clear a forgotten BIOS password on this appliance?

Press the front-panel restart/BIOS reset button while the unit is powered off, then power on; the AMI UEFI BIOS will revert to defaults without opening the chassis.
