Tan fiberglass pipe insulation tube with slit adhesive flap

Owens Corning

Owens Corning 147022 Drain Trap

SKU CH-JPHP-876NF MPN 147022

Fiberglass pipe insulation with ASJ facing, slit adhesive installation, rated for 0 to 1000 °F and R-value 5

  • TypeDrain Components
  • MaterialHAWA
  • ColorTan
  • Operates from 0 °F up to 1,000 °F for extreme temperature resilience
  • R-value 5 insulation reduces heat loss on hot or cold piping
  • ASJ facing with 25 flame spread and 50 smoke developed for plenum safety
  • Slit adhesive flap enables fast, tool-free installation on 5 in pipe
  • Fiberglass construction resists moisture and maintains performance over time

Pipe insulation for 5-inch systems

This Owens Corning fiberglass pipe insulation is made for 5-inch pipes and uses an ASJ facing with a slit, adhesive and flap installation style. It comes in a 3-foot length with a 1-inch wall thickness and an inside diameter of 5 41/64 inches. The tan jacket provides a clean appearance for mechanical rooms or exposed runs.

Suited for hot and cold piping up to 1000 degrees F

It serves contractors and facility managers who need plenum-rated insulation with a flame spread index of 25 and smoke developed index of 50. The R-value of 5 supports energy-code compliance on domestic hot water, hydronic heating and chilled water lines. Installers who require non-fiberglass materials or foam-based products should look at something else.

Operating range from 0 to 1000 degrees Fahrenheit

The minimum operating temperature of 0 degrees F and maximum of 1,000 degrees F define the thermal envelope this insulation can withstand without degradation. Selecting this part depends on confirming the system temperature stays within that range.

Highlights

  • Operates from 0 °F up to 1,000 °F for extreme temperature resilience
  • R-value 5 insulation reduces heat loss on hot or cold piping
  • ASJ facing with 25 flame spread and 50 smoke developed for plenum safety
  • Slit adhesive flap enables fast, tool-free installation on 5 in pipe
  • Fiberglass construction resists moisture and maintains performance over time

Specifications

TypeDrain Components
MaterialHAWA
ColorTan
BrandOwens Corning
Model147022

Questions about this item

Which length and wall thickness suit a 5-inch pipe?

The tube is 3 ft long with a 1 in wall and a 5 41/64 in inside diameter, made for 5 in pipe size.

What does the R-5 rating mean once the insulation is installed?

R-5 indicates the thermal resistance of the 1 in fiberglass wall, reducing heat loss from 0 to 1,000 °F service temperatures.

How does the ASJ facing affect the installation?

The ASJ jacket provides a vapor barrier and meets a 25 flame spread and 50 smoke developed rating for plenum-rated use.
