Black outdoor Cat5E ethernet cable on a wooden spool

Nippon Labs

Nippon Labs 80C5CMXU-1514BK Cat5E outdoor network ethernet cable 1000 ft

SKU CH-0EQT-8EB1Q MPN 80C5CMXU-1514BK

Cat5E outdoor direct-burial cable with solid copper conductors, rated for 350 MHz Gigabit Ethernet runs up to 1000 ft on a wooden spool

  • TypeNetwork Ethernet Cables
  • Cat5E
  • Length1000 ft.
  • ColorBlack
  • ShieldedUTP
  • Wire Gauge24 AWG
  • Supports gigabit speeds with 350 MHz bandwidth rating
  • Solid copper conductors ensure reliable signal over 1000 ft
  • CMX jacket withstands direct burial and UV exposure
  • UTP design with colour-striped pairs simplifies identification
  • Meets TIA 568C.2 and ISO 11801 standards

Outdoor bulk cable

Nippon Labs 80C5CMXU-1514BK is a Category 5E UTP cable built for direct burial and outside plant use. It delivers 1000 ft of 24 AWG solid bare copper conductors in a black PE jacket rated CMX. Installers running Gigabit Ethernet or Fast Ethernet links between buildings use this reel for permanent outdoor infrastructure.

UV resistant jacket and pull box

The polyethylene sheath resists UV exposure and meets CMX requirements for direct burial without conduit. Four colour striped pairs simplify identification during termination, while sequential length markings on the jacket help track remaining cable. A 1000 ft wooden spool feeds cleanly on site and protects the conductors during transport.

Category 5E bandwidth limit

The design supports 350 MHz bandwidth and data rates up to Gigabit Ethernet, Fast Ethernet and 155 Mbps TP-PMD or CDDI. It does not meet Category 6 or higher performance specifications, so installers needing 10 Gigabit Ethernet over copper must select a different cable category. Exceeds TIA 568C.2, ISO/IEC 11801 and YD/T 1019 standards.

Highlights

  • Supports gigabit speeds with 350 MHz bandwidth rating
  • Solid copper conductors ensure reliable signal over 1000 ft
  • CMX jacket withstands direct burial and UV exposure
  • UTP design with colour-striped pairs simplifies identification
  • Meets TIA 568C.2 and ISO 11801 standards

Specifications

BrandNippon Labs
Model80C5CMXU-1514BK
TypeNetwork Ethernet Cables
Cat5E
Length1000 ft.
ColorBlack
ShieldedUTP
Wire Gauge24 AWG
FeaturesHigh-Performance Data Communications Cable
CAT5E Outdoor Direct Burial, Outside Plant
Suitable for 350MHz High-Speed Data Applications, Gigabit Ethernet, Fast Ethernet and 155Mbps TP-PMD/CDDI
Designed for Outdoor Direct Burial Installations (CMX)
Category-5E Unshielded Twisted Pair (UTP) Cable
4-Pair Easily Identified Color Striped Pairs
24 AWG Solid Bare Copper Conductors
Excellent Attenuation and Crosstalk Characteristics
Exceeds TIA 568C.2, ISO/IEC 11801, And YD/T1019 Specifications
RoHS Compliant
Sequential Length Markings On Jacket
Supplied On A 1000' Wooden Spool
Shipping weight9.25 kg
Package size381 × 371 × 210 mm

Questions about this item

What does the Cat 5E rating and 350 MHz bandwidth cap in practice?

The cable is rated for 350 MHz and supports Gigabit Ethernet, Fast Ethernet and 155 Mbps TP-PMD/CDDI applications.

What physical requirements does the 1000 ft outdoor cable have for installation?

It uses 24 AWG solid bare copper conductors with a UV-resistant PE jacket, is CMX rated for direct burial, and comes on a wooden spool with sequential length markings.

How is the solid-conductor UTP cable terminated, and what mistake should be avoided?

Terminate with connectors or punch-down blocks designed for solid 24 AWG copper and follow the colour-striped pair order; do not use components meant for stranded wire.
