Green composite spool with two Cat6 and two RG6 quad shield cables

Nippon Labs

Nippon Labs 60RG6-C6-500 network ethernet cable 500 ft green

SKU CH-WZF0-C9HMJ MPN 60RG6-C6-500

A 500 ft green composite cable containing two Cat 6 UTP runs and two RG6 quad-shield coaxial runs, CMR rated and UL listed

  • TypeNetwork Ethernet Cables
  • Cat6
  • Length500 ft.
  • ColorGreen
  • ShieldedNo
  • Features(X2) Cat6: 24AWG 4 pair solid wire UTP (X2) RG6: 18AWG quad
  • Two Cat6E runs support gigabit networking
  • Two RG6 quad-shield runs carry clean video signals
  • 500 ft single pull simplifies whole-house installs
  • CMR rating meets in-wall fire code
  • UL listed for verified safety compliance

Combo cable for structured wiring

This 500 ft reel bundles two Cat6 UTP runs and two RG6 quad-shield coaxial runs in a single green jacket. It is built for installers pulling data and video distribution together in residential or light-commercial projects. CMR rating and UL listing allow in-wall and riser placement without additional sleeving. Solid bare copper conductors on the Cat6 side meet TIA 568-C.2 for reliable gigabit performance.

Suited for combined data and coax pulls

Electricians and low-voltage contractors who need both network drops and cable or satellite feeds from one pull will save labour and conduit space. Buyers who only need a single Cat6 run or a pure coaxial line should look at single-purpose reels instead. The composite construction adds bulk that is unnecessary for a standalone application.

500 ft composite length decides fit

The fixed 500-foot length determines whether the reel covers the longest home run in the job. Measure the furthest outlet plus slack before ordering; the cable cannot be shortened without waste and cannot be extended without a splice.

Highlights

  • Two Cat6E runs support gigabit networking
  • Two RG6 quad-shield runs carry clean video signals
  • 500 ft single pull simplifies whole-house installs
  • CMR rating meets in-wall fire code
  • UL listed for verified safety compliance

Specifications

BrandNippon Labs
Model60RG6-C6-500
TypeNetwork Ethernet Cables
Cat6
Length500 ft.
ColorGreen
ShieldedNo
Features(X2) Cat6: 24AWG 4 pair solid wire UTP
(X2) RG6: 18AWG quad shield
Green color
CMR rated
UL listed
Two 4 Pair Cat6E UTP Cable
Complies to TIA 568-C.2
23 Awg Solid Bare Copper Conductor / PE Insulation
Two RG6 Quad Shield Coaxial Cable
Complies to SCTE ISP-IP-001
18 Awg Copper Clad Steel (CCS)
Al foil / 60% Al-Mg alloy Braid Shield +
Al foil / 40% Al-Mg alloy Braid Shield
Shipping weight13.61 kg
Package size508 × 457 × 381 mm

Questions about this item

Should I pick the 500 ft combo reel or a shorter length?

The reel supplies 500 ft of composite cable — two Cat6E UTP runs and two RG6 quad-shield coax runs — so choose it when you need that full distance for both data and video drops.

What does the Cat 6 rating deliver once the cable is terminated?

Each Cat6E run uses 23 AWG solid bare copper conductors and meets TIA 568-C.2, supporting gigabit Ethernet performance over the installed length.

How does the CMR rating and UL listing affect where I can run this cable?

CMR rating means the jacket is rated for vertical riser spaces, and the UL listing confirms it meets the relevant safety standard for in-wall installation.
