Large silver rack-tower UPS with touchscreen LCD and multiple outlet types

MINUTEMAN

MINUTEMAN ED8KRT 8000VA 7200W UPS

SKU CH-JYMP-GGD97 MPN ED8KRT

8 kVA / 7200 W rack-tower UPS with true sine-wave output, configurable 208-240 V, hot-swappable batteries and 3 min runtime at full load

  • International Version208 (Default), 220, 230, 240VAC
  • Input Voltage Range180-280VAC
  • Input Frequency40 to 70Hz at Full Load
  • Input ConnectionHardwire only
  • VA Rating8,000VA
  • Watts7200W

Model ED8KRT

Show 16 more configurations
  • 8,000VA capacity protects critical rack equipment
  • True sine-wave output delivers clean power to sensitive loads
  • Hot-swappable BM0098 batteries enable replacement without downtime
  • Touchscreen LCD panel simplifies configuration and monitoring
  • 3,140-joule surge rating shields connected hardware from spikes

8000VA Rack/Tower UPS for Critical Loads

The Minuteman Endeavor ED8KRT is an 8000VA, 7200W true sine-wave UPS built for 208V, 220V, 230V or 240V single-phase environments. It supplies five outlets — four L6-30R, two L6-20R and a three-wire terminal block — making it suitable for server rooms and network closets that need hardwired input and extended runtime options.

Hardwired Install with Hot-Swap Batteries

Input connection is hardwire only, so a qualified electrician must terminate the feed. The unit occupies 5U in a rack and weighs 170.81 lbs, requiring adequate support rails or a stable floor surface. Batteries are front-accessible, tool-less and hot-swappable using the BM0098 pack, allowing replacement without powering down connected equipment.

Check Voltage, Phase and Breaker Capacity

Verify that your supply sits within the 180-280VAC window and that the service is single-phase 50/60Hz. Confirm the distribution panel can deliver the required current for an 8000VA load and that the L6-30R or L6-20R plugs match your gear. The DB-9 port provides basic monitoring; network cards are not included.

Highlights

  • 8,000VA capacity protects critical rack equipment
  • True sine-wave output delivers clean power to sensitive loads
  • Hot-swappable BM0098 batteries enable replacement without downtime
  • Touchscreen LCD panel simplifies configuration and monitoring
  • 3,140-joule surge rating shields connected hardware from spikes

Specifications

BrandMINUTEMAN
SeriesENDEAVOR
ModelED8KRTED6KRT
International Version208 (Default), 220, 230, 240VAC
Input Voltage Range180-280VAC
Input Frequency40 to 70Hz at Full Load
Input ConnectionHardwire only
VA Rating8,000VA
Watts7200W
Output Voltage208 (Default), 220, 230, 240VAC
Output Frequency50/60Hz, +/-0.1Hz
Outlets5
Outlet Type(4) L6-30R / (2) L6-20R / (1) 3-wire Terminal Block
Battery Run TimeHalf Load: 11 min
Full Load: 3 min
Battery ReplaceableBM0098
Interface PortDB-9
ApprovalscUL, CE, UL1778, FCC Class B, Energy Star 2.0, RoHS2
Surge Energy Rating3140 Joules
TemperatureOperating Temperature: +32° to +104°F (0° to +40°C)
Storage Temperature: +5° to +131°F (-15° to +55°C)
Humidity0 to 95%, non-condensing
Dimensions8.54" x 17.24" x 28.74"
Weight170.81 lbs.
Shipping weight77.47 kg
Package size729 × 437 × 216 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How can I confirm the UPS is delivering true sine-wave output at 208 VAC after installation?

The multi-colour touchscreen LCD panel displays real-time output voltage and frequency; verify it reads 208 VAC and 50/60 Hz ±0.1 Hz while the load is connected.

What ships with the ED8KRT and which items must be sourced separately?

The unit includes the 4U rack/tower chassis, internal BM0098 battery modules, DB-9 interface port and terminal-block hardware; input power cables, L6-30R/L6-20R output cords and any external battery cabinets are not included.

Which output voltage version should I select for a 230 VAC server rack?

Choose the 230 VAC international version; the UPS defaults to 208 VAC but can be configured to 220, 230 or 240 VAC via the touchscreen to match your rack’s distribution.
