Maswell Communication Tech. 5G 4x4 MIMO Screw Mount IP67 Network Antenna
Four-element 4x4 MIMO antenna covers 600 MHz to 8.0 GHz with IP67 waterproofing and SMA connectors for outdoor cellular and IoT deployments
- ColorBlack
- 4x4 MIMO covers 600 MHz to 8.0 GHz for broad cellular support
- Each element delivers up to 6.0 dBi gain with 1 m LMR195 cable
- IP67 waterproof rating suits outdoor and industrial environments
- Operates from -40 to +85 °C with 95 % humidity tolerance
- ROHS compliant construction with SMA male connectors for easy integration
5G 4x4 MIMO screw-mount antenna
This Maswell Communication Tech. antenna delivers 5G, 4G, 3G and GSM cellular coverage in a single IP67-rated housing. Four identical elements each operate from 600 MHz to 8.0 GHz with linear polarisation. It suits industrial, commercial and IoT deployments such as hotspots, kiosks, vending machines, point-of-sale terminals, machine-to-machine links, video surveillance, vehicles, SCADA, telemetry, PLCs, RTUs and digital signage. The black reinforced-plastic radome resists vandalism and harsh outdoor conditions.
Four elements up to 6.0 dBi gain
Each of the four antennas provides up to 6.0 dBi gain with a 20 cm cable length, average VSWR of 3.0 and efficiency above 50 percent. The 600 MHz to 8.0 GHz span covers 5G, 4G LTE, WiFi6E and UWB bands simultaneously. Performance tapers at the band edges where VSWR rises, so installers should verify signal quality in fringe coverage areas. The LMR195 cables run 1 metre standard with SMA male connectors.
IP67 housing with 121 mm footprint
The sealed enclosure measures 121 mm by 121 mm by 91 mm and withstands immersion, dust, vibration from 10 to 55 Hz at 1.5 mm amplitude, and temperatures from -40 to +85 °C. Screw mounting secures the unit to metal panels, meter housings, equipment sheds or vehicle roofs without adhesive. Four SMA male pigtails require a router or gateway with four corresponding SMA female ports; devices with fewer antenna ports cannot use all elements. ROHS-compliant materials meet environmental regulations.
Highlights
- 4x4 MIMO covers 600 MHz to 8.0 GHz for broad cellular support
- Each element delivers up to 6.0 dBi gain with 1 m LMR195 cable
- IP67 waterproof rating suits outdoor and industrial environments
- Operates from -40 to +85 °C with 95 % humidity tolerance
- ROHS compliant construction with SMA male connectors for easy integration
Specifications
| Color | Black |
|---|
Questions about this item
Will the 600 MHz to 8.0 GHz range of this 4x4 MIMO antenna work with my existing 4G LTE router?
The antenna covers 600 MHz to 8.0 GHz, which includes all common 4G LTE bands, so it will work with your router if the router uses SMA male connectors.
How can I verify the four antenna elements are performing correctly after installation?
Check signal strength and throughput on each of the four SMA ports; each element should show up to 6.0 dBi gain and better than 50 percent efficiency across the 600 MHz to 8.0 GHz band.
What comes in the box and what must I buy separately?
The antenna unit with four integrated elements, 1 m LMR195 cables and SMA male connectors is supplied; mounting hardware and any adapter cables for non-SMA router ports are not included.
