Black rectangular 8x8 HDMI matrix switch front panel with status LEDs and IR window

LUOM

LUOM OZJ8 8x8 HDMI Matrix Switch 4K 60Hz Seamless Switcher Splitter 3 Modes Charging Head IR

SKU CH-ZW7V-JS5ZR

An 8×8 HDMI matrix routes eight 4K sources to eight displays with seamless switching, 18 Gbps bandwidth, HDR10, 3D and IR remote control

  • TypeHDMI Switchers
  • Changer TypeHDMI Switch/Extender
  • ColorBlack
  • Ports8x8 Matrix
  • MatrixYes
  • AudioYes
  • Routes 8 HDMI sources to 8 displays independently
  • Seamless 4K 60 Hz 4:4:4 switching with HDR10
  • 18 Gbps bandwidth handles 8/10/12-bit deep colour
  • IR, RS-232 and front-panel control options
  • Compact 5.91 × 2.36 × 0.79 in, 11.9 oz

8x8 HDMI Matrix Switch

The LUOM OZJ8 routes up to eight HDMI 2.0b sources to eight displays simultaneously. It handles 4K 60 Hz signals with 4:4:4 chroma sampling and 18 Gbps bandwidth. Installers and AV integrators use it for multi-room distribution, digital signage or conference-room switching where every output needs an independent source selection.

HDMI 2.0b distance limits

The switch equalises and amplifies signals to extend reliable transmission. At 4K 60 Hz the supplier specifies AWG26 cables under 5 metres; at 1080p the same cable gauge reaches 20 metres. RS-232, IR extension and front-panel keys provide control when the unit sits in a rack out of direct line of sight.

Eight inputs and eight outputs

Each of the eight inputs can be routed to any or all of the eight outputs, supporting 3D, deep colour up to 24 bit and audio formats including LPCM 7.1, DTS-HD and Dolby TrueHD. The 600 MHz TMDS clock and 18 Gbps ceiling mean 4K 60 Hz 4:4:4 is the practical maximum; higher refresh rates or 8K resolutions exceed the available bandwidth.

Highlights

  • Routes 8 HDMI sources to 8 displays independently
  • Seamless 4K 60 Hz 4:4:4 switching with HDR10
  • 18 Gbps bandwidth handles 8/10/12-bit deep colour
  • IR, RS-232 and front-panel control options
  • Compact 5.91 × 2.36 × 0.79 in, 11.9 oz

Specifications

BrandLUOM
SeriesOZJ8
ModelOZJ8
Part NumberOZJ8
TypeHDMI Switchers
Changer TypeHDMI Switch/Extender
ColorBlack
Ports8x8 Matrix
MatrixYes
AudioYes
SpecificationsHDMI version: HDMI 2.0b
HDMI resolution: Up to 3840*2160@60Hz; YUV(4:4:4) RGB.
Support video format: 3D, 8/ 10/ 12/ 24 bit deep color.
Max bandwidth: 600MHz
Max band rate: 18Gbps
Input cable distance: less than 8m AWG26 HDMI 2.0b standard cable
Output cable distance: less than 8m AWG26 HDMI 2.0b standard cable
HDMI Matrix Ports: 8*HDMI Input; 8*HDMI Output; 1*RS232 Port; 1*DC 12V Power Port
Switching mode: Manual switching & IR remote control switch
Power adapter format: Input: AC (50HZ, 60HZ) 100V-240V; Output: DC 12V/2A
Max working current: 500mA
Input Connector8 x HDMI
Output Connector8 x HDMI
Maximum Cable Lengthless than 8m AWG26 HDMI 2.0b standard cable
Maximum Resolutions4096 x 2160
Bandwidth18Gbps/600MHZ
Features8 HDMI Input 8HDMI Output: This 8X8 HDMI Matrix routes up to eight 4K HDR HDMI sources to eight 4K HDR display devices. can be used for multiple high-definition digital video inputs and outputs exchange; any one of the signal outputs can be selected from any one of the signal sources without interfering with other outputs.
4K 60Hz Support & Downscale Function: Supports up to 4K 60Hz resolution with support for HDR,3D.Enjoy UHD content as it was intended.And the device supports mixed 4K & 1080p display ports. Each output supports downscale functionality, it can display 4K or downscale
Dimensions5.91 x 2.36 x 0.79 inches
Weight11.9 ounces
Package Quantity1
Package Contents1x HDMI Matrix 8x8
1x 12V power adapter
1x IR Remote Control
1x User Manual

Questions about this item

Should I choose the 8x8 matrix or a smaller switch for my eight sources and eight displays?

The 8x8 matrix routes each of the eight HDMI inputs to any of the eight HDMI outputs independently, so all sources and displays can be active at once.

What does the 18Gbps bandwidth mean when I connect 4K 60Hz sources?

18Gbps carries full 4K 3840x2160 60Hz 4:4:4 RGB or YUV without compression, so HDR10 and deep colour up to 12-bit pass through unchanged.

How far can I run cables on the HDMI 2.0b ports at 4K resolution?

The spec lists less than 5 metres with AWG26 cable for 4K, and less than 20 metres for 1080p signals.
