Black rectangular 8x8 HDMI matrix switch 5.91 x 2.36 x .79 inches

LUOM

LUOM OZJ8 8x8 HDMI Matrix Switch 4K 60Hz 18Gbps

SKU CH-09QQ-8BA7Z

Routes eight 4K 60 Hz HDMI sources to eight displays with 18 Gbps bandwidth, HDCP 2.2, HDR, 3D and 7.1 audio

  • TypeHDMI Switchers
  • Changer TypeHDMI Switch/Extender
  • ColorBlack
  • Ports8x8 Matrix
  • MatrixYes
  • AudioYes
  • Routes 8 sources to 8 displays independently
  • 18Gbps bandwidth carries 4K 60Hz 4:4:4 HDR
  • HDCP 2.2 protects premium 4K content
  • RS232 plus IR enable full system integration
  • 9 oz chassis fits tight rack spaces

8×8 HDMI Matrix Switch

The LUOM OZJ8 routes up to eight 4K HDR sources to eight displays simultaneously. It suits installers who need any input mapped to any output in conference rooms, classrooms or retail walls. The unit handles HDMI 2.0b signals with HDCP 2.2 compliance and 18 Gbps bandwidth.

Remote IR RS232 and EDID control

Bundled infrared extension, IR transmitter and RS-232 ports let operators switch sources from a distance or automate changes through a control system. EDID management keeps every connected display recognised without manual reconfiguration.

4K 60 Hz 4:4:4 over short cables

Each path supports 3840×2160 at 60 Hz with 8, 10, 12 or 24 bit deep colour and 7.1 audio formats. The 18 Gbps link is rated for cables under 5 metres at 4K and under 20 metres at 1080p; longer runs or higher refresh rates exceed the specified headroom.

Highlights

  • Routes 8 sources to 8 displays independently
  • 18Gbps bandwidth carries 4K 60Hz 4:4:4 HDR
  • HDCP 2.2 protects premium 4K content
  • RS232 plus IR enable full system integration
  • 9 oz chassis fits tight rack spaces

Specifications

BrandLUOM
SeriesOZJ8
ModelOZJ8
Part NumberOZJ8
TypeHDMI Switchers
Changer TypeHDMI Switch/Extender
ColorBlack
Ports8x8 Matrix
MatrixYes
AudioYes
SpecificationsHDMI version: HDMI 2.0b
HDMI resolution: Up to 3840*2160@60Hz; YUV(4:4:4) RGB.
Support video format: 3D, 8/ 10/ 12/ 24 bit deep color.
Max bandwidth: 600MHz
Max band rate: 18Gbps
Input cable distance: less than 8m AWG26 HDMI 2.0b standard cable
Output cable distance: less than 8m AWG26 HDMI 2.0b standard cable
HDMI Matrix Ports: 8*HDMI Input; 8*HDMI Output; 1*RS232 Port; 1*DC 12V Power Port
Switching mode: Manual switching & IR remote control switch
Power adapter format: Input: AC (50HZ, 60HZ) 100V-240V; Output: DC 12V/2A
Max working current: 500mA
Input Connector8 x HDMI
Output Connector8 x HDMI
Maximum Cable Lengthless than 8m AWG26 HDMI 2.0b standard cable
Maximum Resolutions4096 x 2160
Bandwidth18Gbps/600MHZ
Features8 HDMI Input 8HDMI Output: This 8X8 HDMI Matrix routes up to eight 4K HDR HDMI sources to eight 4K HDR display devices. can be used for multiple high-definition digital video inputs and outputs exchange; any one of the signal outputs can be selected from any one of the signal sources without interfering with other outputs.
4K 60Hz Support & Downscale Function: Supports up to 4K 60Hz resolution with support for HDR,3D.Enjoy UHD content as it was intended.And the device supports mixed 4K & 1080p display ports. Each output supports downscale functionality, it can display 4K or downscale
Dimensions5.91 x 2.36 x 0.79 inches
Weight11.9 ounces
Package Quantity1
Package Contents1x HDMI Matrix 8x8
1x 12V power adapter
1x IR Remote Control
1x User Manual

Questions about this item

Will the HDMI 2.0b ports need firmware updates to maintain HDCP 2.2 compliance?

The matrix runs HDMI 2.0b with HDCP 2.2 built in; no user firmware updates are required for compliance.

At 18Gbps bandwidth, what limits 4K 60Hz 4:4:4 transmission over long cables?

4K 60Hz signals stay reliable up to 5 metres on AWG26 cable; 1080p reaches 20 metres on the same gauge.

Does the 600MHz TMDS clock generate noticeable heat or fan noise during all-day operation?

The unit is passively cooled, silent, and draws little power; it stays cool enough for continuous 24/7 use.
