Black rectangular 8x8 HDMI matrix switch with front panel ports and IR receiver

LUOM

LUOM OZJ8 8x8 HDMI Matrix 4K 60Hz 18Gbps video switch

SKU CH-D69V-084EH

An 8×8 HDMI matrix routes eight 4K 60Hz sources to eight displays with per-output downscale to 1080p, IR remote, RS232 control, 18Gbps bandwidth and support for 7.1 audio formats

  • TypeHDMI Switchers
  • Changer TypeHDMI Switch/Extender
  • ColorBlack
  • Ports8x8 Matrix
  • MatrixYes
  • AudioYes
  • Routes 8 HDMI sources to 8 displays independently
  • 4K 60Hz HDR video with 18Gbps bandwidth
  • Downscale each output from 4K to 1080p automatically
  • IR remote RS232 and front-panel control included
  • Compact 5.91 x 2.36 x 0.79 inch metal chassis

8x8 HDMI Matrix for multi-display routing

The LUOM OZJ8 is an 8x8 HDMI matrix switch that routes up to eight 4K HDR sources to eight independent displays. It accepts eight HDMI inputs and provides eight HDMI outputs with full matrix switching. Any output can select any input without affecting the others. The unit is designed for installers and AV professionals who need simultaneous distribution across multiple screens.

Replaces basic splitters and single-output switches

Unlike a simple splitter that duplicates one source everywhere, this matrix lets each display show a different 4K source at the same time. It upgrades installations that previously relied on manual cable swapping or multiple single-input switchers. The jump is worth it when a venue needs flexible, independent routing to eight screens from a central rack.

Handles 4K 60Hz 4:4:4 and downscales per output

Each output supports 3840x2160 at 60Hz with YUV 4:4:4 colour and 8, 10, or 12-bit deep colour, plus 4096x2160 resolution. Maximum bandwidth is 18Gbps at 600MHz. Input cables should stay under 8 metres with AWG26 HDMI 2.0b cable; 4K transmission is reliable up to 5 metres while 1080p reaches 20 metres. Per-output downscaling converts 4K to 1080p when a display cannot accept the higher signal. Audio passes through formats including LPCM 7.1, DTS-HD and Dolby TrueHD. Control is via IR remote, IR extender and RS232.

Highlights

  • Routes 8 HDMI sources to 8 displays independently
  • 4K 60Hz HDR video with 18Gbps bandwidth
  • Downscale each output from 4K to 1080p automatically
  • IR remote RS232 and front-panel control included
  • Compact 5.91 x 2.36 x 0.79 inch metal chassis

Specifications

BrandLUOM
SeriesOZJ8
ModelOZJ8
Part NumberOZJ8
TypeHDMI Switchers
Changer TypeHDMI Switch/Extender
ColorBlack
Ports8x8 Matrix
MatrixYes
AudioYes
SpecificationsHDMI version: HDMI 2.0b
HDMI resolution: Up to 3840*2160@60Hz; YUV(4:4:4) RGB.
Support video format: 3D, 8/ 10/ 12/ 24 bit deep color.
Max bandwidth: 600MHz
Max band rate: 18Gbps
Input cable distance: less than 8m AWG26 HDMI 2.0b standard cable
Output cable distance: less than 8m AWG26 HDMI 2.0b standard cable
HDMI Matrix Ports: 8*HDMI Input; 8*HDMI Output; 1*RS232 Port; 1*DC 12V Power Port
Switching mode: Manual switching & IR remote control switch
Power adapter format: Input: AC (50HZ, 60HZ) 100V-240V; Output: DC 12V/2A
Max working current: 500mA
Input Connector8 x HDMI
Output Connector8 x HDMI
Maximum Cable Lengthless than 8m AWG26 HDMI 2.0b standard cable
Maximum Resolutions4096 x 2160
Bandwidth18Gbps/600MHZ
Features8 HDMI Input 8HDMI Output: This 8X8 HDMI Matrix routes up to eight 4K HDR HDMI sources to eight 4K HDR display devices. can be used for multiple high-definition digital video inputs and outputs exchange; any one of the signal outputs can be selected from any one of the signal sources without interfering with other outputs.
4K 60Hz Support & Downscale Function: Supports up to 4K 60Hz resolution with support for HDR,3D.Enjoy UHD content as it was intended.And the device supports mixed 4K & 1080p display ports. Each output supports downscale functionality, it can display 4K or downscale
Dimensions5.91 x 2.36 x 0.79 inches
Weight11.9 ounces
Package Quantity1
Package Contents1x HDMI Matrix 8x8
1x 12V power adapter
1x IR Remote Control
1x User Manual

Questions about this item

What rack space does the 5.91 x 2.36 x 0.79 inch chassis require?

The unit measures 5.91 inches wide, 2.36 inches deep and .79 inches high, so it fits on a standard shelf or in a 1U rack tray without special brackets.

Which control method must be configured first — IR, RS232 or front-panel buttons — to avoid conflicting routing commands?

Power the matrix, connect sources and displays, then set the desired input-output map using the front-panel buttons before enabling IR or RS232 control; this prevents the remote or serial commands from overwriting an unset routing table.

When should the HDMI cables be replaced to maintain 4K 60Hz 18Gbps performance?

Replace any cable longer than 5 metres AWG26 when 4K 60Hz signals show sparkles or dropouts; for 1080p runs the limit extends to 20 metres AWG26 before signal degradation requires new cables.
