Small black rectangular DisplayPort switch with two female ports on one side, one on the other, LED indicator

LUOM

LUOM A0201 bidirectional DisplayPort switch 16K 60Hz 4K 240Hz 40Gbps

SKU CH-TA9E-ATG5H

A bidirectional DisplayPort 2.0 switch routes one source to two displays or two sources to one display at up to 16K 60 Hz, 4K 240 Hz and 40 Gbps

  • TypeDisplayPort Splitters
  • Changer TypeDisplay Extenders
  • Ports2
  • AudioYes
  • ColorBlack
  • Specifications1. 16K DP 2.0 Switch: Support 16K@60Hz,8K@60Hz,4K@240Hz reso
  • Bidirectional switching lets two PCs share one monitor or one PC toggle between two displays
  • Supports 16K resolution at 60 Hz and 4K at 240 Hz for ultra-high-definition visuals
  • 40 Gbps bandwidth ensures lossless video transmission at maximum supported resolutions
  • LED indicator shows which source or display is active for instant status checks
  • Compact 5.31 x 3.11 x .87 inch form factor fits neatly on any desk

16K DisplayPort Switch for Dual-PC

The LUOM A0201 is a bidirectional DisplayPort 2.0 switch that routes a single 16K 60 Hz signal between two sources and one display or one source and two displays. It handles 40 Gbps bandwidth and includes an LED indicator to show the active port. External power via USB-C is required for operation.

Ideal for Users Swapping Between Two Computers

This switch suits anyone who needs to toggle a high-refresh 4K 240 Hz or 16K 60 Hz monitor between a workstation and a gaming PC without unplugging cables. It does not support simultaneous output to both connected displays, so buyers wanting extended or mirrored desktops across two monitors should look elsewhere.

40 Gbps Bandwidth Enables 16K 60 Hz and 4K 240 Hz

The single specification that decides fit is the 40 Gbps DisplayPort 2.0 link, which carries 16K at 60 Hz, 8K at 60 Hz, 4K at 240 Hz and 1080p at 240 Hz. Both the source and the display must support the target resolution and a certified DP 2.0 cable must be used on each side.

Highlights

  • Bidirectional switching lets two PCs share one monitor or one PC toggle between two displays
  • Supports 16K resolution at 60 Hz and 4K at 240 Hz for ultra-high-definition visuals
  • 40 Gbps bandwidth ensures lossless video transmission at maximum supported resolutions
  • LED indicator shows which source or display is active for instant status checks
  • Compact 5.31 x 3.11 x .87 inch form factor fits neatly on any desk

Specifications

BrandLUOM
SeriesA0201
ModelA0201
Part NumberA0201
TypeDisplayPort Splitters
Changer TypeDisplay Extenders
Ports2
AudioYes
ColorBlack
Specifications1. 16K DP 2.0 Switch: Support 16K@60Hz,8K@60Hz,4K@240Hz resolution, provide you with transfer rates up to 40Gbps and backward compatible with all previous DP standards.
?
2: The DisplayPort switcher allow you to connect two DP source to one DP display or connect one DisplayPort source to toggle between two displays.
?
3. External power required, the DP selector box is easy to setup and operate. Note: While using, press "select"Button to switch signal between two sources or displays, the indicator lights show the working status, two displays CANNOT display simultaneously.
?
4. This di
Input Connector1x DisplayPort female
Output Connector2x DisplayPort female
Connector StyleFemale
Maximum ResolutionsSupport 16K@60Hz,8K@60Hz,4K@240Hz,4K@144Hz,1080P@240Hz resolution,
Bandwidth40Gbps
FeaturesBi-Direction ***DP Switch:The DisplayPort Switcher allow you to connect two DP source to one DP display or connect one DisplayPort source to toggle between two displays. (Two displays CANNOT display simultaneously,Press"Select"button to switch between two displays.)(While connecting to Source or Display,you must use the usb cable to power the splitter,or your display can not show anything).Do not use too long cable(total 2m) for connection between the switcher and your devices.
16K DP 1.4 Splitter: Support 8K@120Hz,4K@240Hz,1080P@240Hz resolution, provide you with transfer rates up t
Dimensions5.31 x 3.11 x 0.87 inches
Weight2.12 Ounces
Package Quantity1
Package Contents1x Bi-Direction DP Switch, Power Charging Cable x1, User Manual x1.

Questions about this item

What is the maximum combined cable length this switch supports before signal loss?

The manufacturer recommends the total length of input and output cables not exceed 2 meters to avoid signal shielding.

How do you connect two PCs to one monitor using this switch?

Plug each PC into the DP1 and DP2 ports with DisplayPort cables, connect the monitor to the DP port, then use the selector button to switch between sources.

What cable standard is required to achieve the 16K 60Hz capability?

You must use a standard DisplayPort 2.0 cable rated for 16K on both the input and output sides to reach the maximum resolution and 40Gbps bandwidth.
