LR-LINK 40G QSFP+ active optical cable, 5 metre length, black jacketed round cable with QSFP+ connectors both ends

LR-LINK

LR-LINK QSFP+-AOC-5M 40G QSFP+ Active Optical Cable 5M/16FT

SKU CH-5XP6-Q8MQ3

A 40 Gbps QSFP+ active optical cable with four full-duplex channels at 11.3 Gbit/s each, under 1.5 W power draw and hot-pluggable for rack links up to 16 ft

  • TypeNetwork Ethernet Cables
  • 40G total bandwidth from 4 channels at 11.3Gbit/s each
  • Under 1.5W draw keeps rack power budgets low
  • Hot-pluggable QSFP+ form factor enables live swaps
  • Operates from 0°C to 70°C in commercial use
  • Light active optical cable replaces heavier copper DACs

40G QSFP+ Active Optical Cable

This LR-LINK active optical cable delivers 40G Ethernet connectivity over a 5 metre or 16 foot reach. It uses four full-duplex channels running at up to 11.3 Gbit/s each for an aggregate 45.2 Gbit/s throughput. The QSFP+ form factor is hot-pluggable and compliant with the IEEE 802.3ba standard.

VCSEL array and low power draw

The cable employs reliable VCSEL array technology over multimode fibre, consuming less than 1.5 W from a single 3.3 V supply. Compared with traditional direct-attach copper cables, the optical construction is lighter and has a smaller diameter, easing cable routing inside the rack. Standard lengths of 3, 15 and 30 metres are also available.

Hot-plug installation and temperature limits

Installation is a simple hot-plug into any compliant QSFP+ port with no tools required. The commercial temperature range spans 0 to 70 °C and an industrial range of -40 to +85 °C is specified, so deployments outside climate-controlled rooms need the industrial-rated variant. Ensure the switch port supports 40G Ethernet IEEE 802.3ba to avoid link negotiation issues.

Highlights

  • 40G total bandwidth from 4 channels at 11.3Gbit/s each
  • Under 1.5W draw keeps rack power budgets low
  • Hot-pluggable QSFP+ form factor enables live swaps
  • Operates from 0°C to 70°C in commercial use
  • Light active optical cable replaces heavier copper DACs

Specifications

BrandLR-LINK
ModelQSFP+-AOC-5M
TypeNetwork Ethernet Cables

Questions about this item

Will the +3.3 V single power supply need any maintenance or replacement during the cable's life?

No, the cable draws under 1.5 W from the host QSFP+ port and has no user-serviceable power components.

What limit appears first when running 40 G Ethernet continuously?

The commercial operating ceiling of 70 °C is the first thermal limit under sustained load.

How much heat and noise does the 5 m active optical cable produce in all-day operation?

It consumes less than 1.5 W, generates minimal heat, and has no moving parts so it runs silently.
