Green circuit board with two blue USB 3.0 Type-A ports and a full-height metal bracket

LORDWORLD

LORDWORLD U3023 2-Port USB 3.0 Type-A PCIe Expansion Card

SKU CH-FRJ3-5MG8S

Adds two USB 3.0 Type-A ports via PCIe x1 with 5 Gbps shared bandwidth, dual 5 V 2 A power groups and solid-state capacitors for stable high-speed data on Windows, Linux and ARM platforms

  • Adds two USB 3.0 Type-A ports via a single PCI-Express x1 slot
  • NEC720202 controller delivers shared 5 Gbps bandwidth over PCIe 2.0 x1
  • Dual power groups supply 5 V 2 A each for high-power devices such as industrial cameras and NVME enclosures
  • High-frequency ceramic and solid-state capacitors on every port stabilise high-speed data transfer
  • Plug-and-play on Windows 11, 10, 8 and Server 2012, 2016, 2019, 2022 plus most Linux kernels

Two-port USB 3.0 add-in card

The LORDWORLD U3023 adds two Type-A USB 3.0 ports to a desktop PC, server or NAS through a single PCI-Express x1 slot. It is built around the NEC720202 controller and works with Intel, AMD and ARM platforms. Windows 11, 10, 8 and Server 2012 through 2022 plus most Linux kernels support it without extra drivers. Mac OS is not supported.

Shared 5 Gbps PCIe 2.0 x1 link

Both ports share the 5 Gbps bandwidth of a PCIe 2.0 x1 connection, so simultaneous high-speed transfers divide that throughput. This ceiling decides whether the card can sustain the data rates your devices need.

Self-powered with per-port 5 V 2 A

Each USB port has its own 5 V 2 A power group backed by high-frequency ceramic and solid-state capacitors for stable voltage. The card draws all power from the slot, needs no auxiliary connector and runs silently with no active cooling. It fits standard-height brackets only, not slim or compact cases.

Highlights

  • Adds two USB 3.0 Type-A ports via a single PCI-Express x1 slot
  • NEC720202 controller delivers shared 5 Gbps bandwidth over PCIe 2.0 x1
  • Dual power groups supply 5 V 2 A each for high-power devices such as industrial cameras and NVME enclosures
  • High-frequency ceramic and solid-state capacitors on every port stabilise high-speed data transfer
  • Plug-and-play on Windows 11, 10, 8 and Server 2012, 2016, 2019, 2022 plus most Linux kernels

Specifications

BrandLORDWORLD

Questions about this item

How does the shared 5Gbps bandwidth affect two NVME drives running at once?

Both ports share the single PCIe 2.0 x1 lane, so simultaneous transfers split the 5Gbps ceiling rather than each getting a full 5Gbps pipe.

What does the PCIe 2.0 x1 interface cap in real-world throughput?

The PCIe 2.0 x1 link limits aggregate throughput to 5Gbps, which both USB 3.0 Type-A ports divide between them.

Will the included bracket fit a slim or compact desktop case?

The card ships with a regular-profile bracket only and is not suitable for slim or compact cases.
