White 18/2 shielded security cable in pull box

Logico

Logico PLC4508 18/2 Shielded Security Cable 1000ft 305m White

SKU CH-J6T9-0PDB8

18 AWG two-conductor shielded stranded bare copper cable rated CMR and CL3R for security, access control and low-voltage installations, supplied in a 1000-foot pull box

  • TypeSecurity & Motion
  • ColorWhite
  • 18 AWG shielded pair protects low-voltage signals from interference
  • Stranded bare copper conductors simplify pulling and termination in tight spaces
  • CMR and CL3R ratings allow in-wall and riser installations per code
  • 1000 ft / 305 m pull box provides continuous length for large projects
  • White PVC jacket blends with ceilings and walls for discreet runs

18/2 Shielded Cable for Low-Voltage Security

This Logico PLC4508 cable supplies 18 AWG two-conductor shielded wiring for hardwired security and access-control installations. Stranded bare copper conductors provide flexibility during pulls. The CMR and CL3R ratings allow in-wall and riser routing. A 1000-foot length in a pull box covers multi-zone projects.

Suits installers running sensors keypads

Builders wiring door contacts window sensors motion detectors or keypads will find the shielded pair reduces interference on long runs. Projects that require plenum-rated cable or higher conductor counts need a different specification. The white jacket blends with standard trim.

Fits into structured-wiring builds

The cable feeds from a pull box into raceways or open joist bays rated for CMR use. Shielding connects to ground at the panel to drain noise from sensor circuits. The 305-metre reel length reduces splice points across large homes or small commercial spaces.

Highlights

  • 18 AWG shielded pair protects low-voltage signals from interference
  • Stranded bare copper conductors simplify pulling and termination in tight spaces
  • CMR and CL3R ratings allow in-wall and riser installations per code
  • 1000 ft / 305 m pull box provides continuous length for large projects
  • White PVC jacket blends with ceilings and walls for discreet runs

Specifications

BrandLOGICO
ModelPLC4508
TypeSecurity & Motion
ColorWhite

Questions about this item

What connectors or terminals do I need to terminate the 18AWG stranded conductors on this PLC4508 cable?

Use connectors rated for 18AWG stranded bare copper such as screw terminals, crimp spades or IDC blocks; strip each conductor cleanly and ensure the shield is grounded at the panel end only.

Can I run this CMR/CL3R shielded cable in the same conduit as existing non-shielded 18/2 alarm wire?

Yes, the overall foil shield on the PLC4508 reduces crosstalk so it can share conduit with older unshielded runs, but keep the shield grounded at one end to avoid ground loops.

How do I verify the shield continuity after pulling the 305m reel?

With the cable de-energised, measure resistance between the drain wire at both ends; a low-ohm reading confirms the shield is intact across the full 1000ft length.
