White RG6 coaxial cable on a 1000ft pull box

Logico

Logico COX3501 RG6 Quad Shield Coaxial Cable 18AWG 1000ft White

SKU CH-1Q3A-GHHD6

Quad-shield RG6 coaxial cable with 18AWG copper-clad steel conductor, rated to 3.0 GHz and supplied in a 1,000 ft pull box

  • TypeOther
  • 1000 ft pull box simplifies long cable runs
  • Quad shield construction blocks interference up to 3.0 GHz
  • 18 AWG copper-clad steel conductor carries HDTV and satellite signals
  • CM rated PVC jacket meets flame-retardant safety standards
  • Sequential length markings on jacket speed up installation

Surveillance-Grade Coaxial Cable

This RG6U quad-shield coaxial cable is built for surveillance, digital HDTV, CATV and satellite installations. The 1,000-foot pull box supplies continuous length for long runs between cameras, antennas and distribution points. Installers and system integrators receive a single reel that covers large premises without splices.

Quad Shield Construction and CM Jacket

Four shielding layers — bonded foil, 60-percent aluminum braid, unbonded foil and 40-percent aluminum braid — reject interference across the 3.0 GHz sweep-tested bandwidth. The PVC flame-retardant CM-rated jacket meets in-wall fire codes and carries sequential length markings for easy measuring during pulls. Gas-injected foam polyethylene dielectric maintains consistent impedance over the full 305-meter reel.

18AWG Copper-Clad Steel Conductor

The solid 18AWG copper-clad steel center conductor (1.02 mm) determines signal loss and mechanical strength for each run. Buyers who need solid copper for PoE or lower attenuation should select a different cable type.

Highlights

  • 1000 ft pull box simplifies long cable runs
  • Quad shield construction blocks interference up to 3.0 GHz
  • 18 AWG copper-clad steel conductor carries HDTV and satellite signals
  • CM rated PVC jacket meets flame-retardant safety standards
  • Sequential length markings on jacket speed up installation

Specifications

BrandLOGICO
ModelCOX3501
TypeOther

Questions about this item

What frequency range does the RG6 quad-shield cable support for TV and satellite signals?

The cable is sweep-tested to 3,000 MHz and rated for 3.0 GHz, covering digital HDTV, CATV and SMATV applications.

What are the physical dimensions of the conductor and shielding layers?

It uses an 18 AWG (1.02 mm) copper-clad steel centre conductor, bonded foil, 60 % braid (5×16×0.16 mm), unbonded foil and 40 % braid (4×16×0.16 mm).

How is the 1,000 ft cable packaged for pulling, and what length markings does it carry?

It ships in a pull box with a white CM-rated PVC jacket printed with sequential footage markings for easy measurement.
