Small box camera with 6mm CS-mount lens and RJ45 port

LevelOne

LevelOne FCS-1091 640x480 analog camera PoE 6mm CS-mount

SKU CH-7XRC-Y99YH MPN FCS-1091

Wired analog network camera with 6 mm CS-mount lens, 640 x 480 resolution, PoE power and two-way audio

  • Network CameraYes
  • TypeWired Camera
  • Connection TypeRJ45
  • Ports1 xRJ-45 10/100Mbps port 1 x Microphone Input 3.5 mm Phone J
  • Networking ProtocolTCP/IP, DHCP, SMTP, NTP, HTTP, HTTPS, UPnP, FTP, RTP, RTSP
  • Sensor & DetectorSony 1CX098BO 1 /4" CCD Sensor
  • Powered over Ethernet for single-cable installation
  • Sony 1/4" CCD sensor delivers 640 x 480 resolution
  • Day/Night viewing with automatic IR filter switching
  • Four motion detection zones with individual sensitivity settings
  • Bi-directional audio via 3.5 mm microphone input and speaker output

Product overview

The LevelOne FCS-1091 is a wired analog network camera with a 640 x 480 Sony CCD sensor. It connects through a single 10/100 Mbps RJ45 port and draws power over Ethernet. A 6 mm CS-mount fixed lens and 0.5 lux minimum illumination suit general surveillance duties.

Intended use

Installers needing a simple PoE camera for home, business or public-facility monitoring will find the MJPEG and MPEG-4 streams, day/night IR switching and four configurable motion zones practical. Buyers who want higher resolution, varifocal optics or onboard recording should look at other models.

Deciding specification

The maximum capture resolution is 640 x 480 at 30 fps NTSC or 25 fps PAL, which defines the detail level available for identification and the bandwidth each stream consumes.

Highlights

  • Powered over Ethernet for single-cable installation
  • Sony 1/4" CCD sensor delivers 640 x 480 resolution
  • Day/Night viewing with automatic IR filter switching
  • Four motion detection zones with individual sensitivity settings
  • Bi-directional audio via 3.5 mm microphone input and speaker output

Specifications

BrandLevelOne
ModelFCS-1091
Network CameraYes
TypeWired Camera
Connection TypeRJ45
Ports1 xRJ-45 10/100Mbps port
1 x Microphone Input 3.5 mm Phone Jock
1 x Speokers Output 3.5 mm Phone Jack
Networking ProtocolTCP/IP, DHCP, SMTP, NTP, HTTP, HTTPS, UPnP, FTP, RTP, RTSP
Sensor & DetectorSony 1CX098BO 1 /4" CCD Sensor
MAX Resolution640 x 480
Video Capture Resolution640 x 480, 320 x 240, 160 x 128
Frame Rate640x480, 320x240, 160x120 @ 30 fps NTSC
640x480, 320x240, 160x120 @ 25 fps PAL
Lens Type6mm CS-Mount Type, Fixed Focus Lens, Fl .6
0.5 Lux minimum illumination
Power over EthernetYes
FeaturesSuitable for home, business or public facilities
Supports MJPEG and MPEG-4 video compression standards
Day/Night viewing with automatic IR filter switching
4 Motion Detection Areas with individual sensitivity set-up
Features a bi-directional microphone for easy setup as an intercom with display
Dual live video streaming to multiple users
Remote viewing over the Internet or via 3G Mobile phone. This feature depends on the local mobile telecom system and the mobile phone model. LevelOne does not guarantee that this feature will work in all countries
Features Motion Detection and Event-
Shipping weight1.36 kg
Package size203 × 203 × 152 mm

Questions about this item

What bandwidth does the 10/100 RJ45 port cap the FCS-1091 at in practice?

The single RJ45 port is limited to 10/100 Mbps, so video streams and PoE power share a maximum of 100 Mbps throughput.

What physical mount and lens diameter does the 6 mm CS-mount lens require?

The camera uses a CS-mount thread and ships with a fixed 6 mm lens; no separate lens barrel or adapter is needed for installation.

How is the FCS-1091 powered and configured, and what step do installers often miss?

Connect the RJ45 cable to a PoE switch or injector for both power and data, then assign a static IP or enable DHCP; forgetting to enable DHCP or set a matching subnet is the most common setup error.
