White PTZ dome camera with cylindrical lens housing and mounting base

KT&C

KT&C KPT-SPDN120HD PTZ analog camera 12x optical zoom 1920x1080

SKU CH-ASTT-EKMT2

A PTZ camera with 12x optical zoom, 1920x1080 resolution, 360° pan and IP66 weather resistance

  • TypePTZ Camera
  • Connection TypeCable
  • Sensor & Detector2.1 Megapixel, 1/3? SONY Progressive CMOS
  • MAX Resolution1920 x 1080
  • Lens Type12x Optical Zoom Lens
  • PowerAC 24V (±10%), Max. 25W (Heater on)
  • 1 megapixel Sony CMOS delivers 1920 x 1080 HD-SDI clarity
  • 12x optical plus 10x digital zoom covers 5 to 60 mm focal range
  • 360° endless pan and 180° tilt give full site coverage
  • IP66 rated housing withstands outdoor weather exposure
  • 210 presets with 8 scans, patterns and tours automate surveillance routines

PTZ Camera with 12x Optical Zoom

The KT&C KPT-SPDN120HD is a pan-tilt-zoom camera built for analogue CCTV systems that need remote directional control. It delivers a 2.1 megapixel image through an HD-SDI output, making it suitable for installers upgrading existing coaxial infrastructure to full HD resolution.

1920 x 1080 Resolution and 12x Zoom Range

The 1/3-inch SONY Progressive CMOS sensor captures at 1920 x 1080 pixels with a 12x optical zoom lens spanning 5 to 60 millimetres, supplemented by 10x digital zoom. Minimum illumination of 1 Lux combined with true day/night switching via an ICR mechanism maintains visibility in low light, while 3D DNR, WDR and BLC handle challenging contrast scenes.

Replaces Fixed Analog Cameras Needing Wider Coverage

This unit replaces static analogue cameras when a single mounting point must monitor large areas such as car parks, warehouses or perimeters. The 360-degree endless pan, 180-degree tilt and 210 preset positions with eight tours, scans and patterns automate patrol routes that would otherwise require multiple fixed cameras and additional cabling.

Highlights

  • 1 megapixel Sony CMOS delivers 1920 x 1080 HD-SDI clarity
  • 12x optical plus 10x digital zoom covers 5 to 60 mm focal range
  • 360° endless pan and 180° tilt give full site coverage
  • IP66 rated housing withstands outdoor weather exposure
  • 210 presets with 8 scans, patterns and tours automate surveillance routines

Specifications

BrandKT&C
ModelKPT-SPDN120HD
TypePTZ Camera
Connection TypeCable
Sensor & Detector2.1 Megapixel, 1/3? SONY Progressive CMOS
MAX Resolution1920 x 1080
Lens Type12x Optical Zoom Lens
PowerAC 24V (±10%), Max. 25W (Heater on)
Features2.1 Megapixel, 1/3? SONY Progressive CMOS
HD-SDI (Serial Digital Interface Type Video Output)
f = 12x Optical / 10x Digital Zoom (5 ~ 60 mm)
12x Optical Zoom Lens
True Day & Night with ICR Mechnism
Min. Illumination of 0.1 lux in b/w, 0.2 lux in color
Pan 360° Endless Rotation, Tilt 180° Vector scan
210 Preset (except Short-cut command)
8 Auto Scan / 8 Pattern / 8 Tours consist of Presets
3D DNR / WDR / BLC / OSD
Standard protocols including Pelco-D/P
IP66 (Weather Resistant)
AC 24 V Power

Questions about this item

Will the HD-SDI output from this KPT-SPDN120HD connect directly to my existing analog DVR?

No, the camera uses HD-SDI serial digital interface output which requires a compatible HD-SDI DVR or encoder; it will not work with standard analog CVBS inputs.

How can I verify the 12x optical zoom and 360° endless pan are functioning after installation?

Use the OSD menu via a Pelco-D controller to run a preset tour covering the 5–60 mm zoom range and confirm continuous 360° pan rotation with 180° tilt vector scan.

Does the box include the AC 24 V power supply and mounting hardware, or must I buy them separately?

The camera requires AC 24 V (±10%) at up to 25 W with heater on; the power supply and any mounting brackets are not included and must be sourced separately.
