Aluminium-cased DC-DC converter module, rectangular with mounting ears, IP67 rated

KEHIPI

KEHIPI 9V-36V to 12V 5A 60W Power Adapter

SKU CH-SYK8-K1J2X

Converts 9 V to 36 V input into a stable 12 V output at up to 5 A with 60 W capacity, IP67 waterproofing and over 90 % efficiency

  • ColorAluminium Shell
  • Weight0.109 kilograms
  • Wide input range 9 V to 36 V suits many DC sources
  • Fixed 12 V output at up to 5 A delivers 60 W
  • Conversion efficiency above 90 % keeps heat low
  • IP67 rated aluminium shell resists water dust and shock
  • Over-current and over-temperature protection guards connected equipment

DC 9V-36V Input to 12V 5A Output

This KEHIPI boost-buck converter accepts a DC input range of 9V to 36V and delivers a fixed 12V output at up to 5A, providing 60W of continuous power. It is built for installers who need to run 12V equipment such as car audio, LCD televisions, LED display screens, solar power systems or monitoring alarms from a variable vehicle or battery supply. The aluminium shell is potted to an IP67 rating, making the unit waterproof, dust-proof, moisture-proof and shock-proof for outdoor, underground or mobile use.

Wiring and Mounting Notes

The module measures 2.24 by 1.54 by 0.87 inches and includes mounting ears with a 0.16-inch diameter for secure fixing. Connection must follow the supplied wiring instruction exactly; use short, thick input and output cables to minimise voltage drop and ensure full rated power. Do not parallel multiple output wires to a single load. Conversion efficiency exceeds 90 per cent, so heat is low, but the non-isolated design means input and output grounds are common and must be tied together.

Pre-Installation Checks

Verify that your source voltage stays within the 9V to 36V window under all load conditions, including cranking dips or solar open-circuit peaks. Confirm the total connected load will not exceed 5A at 12V, leaving a margin for long-term stable operation as the manufacturer advises. The operating temperature range spans -25 to 65 degrees Celsius and storage range -40 to 80 degrees Celsius; ensure the mounting location meets these limits. Note that short-circuit protection is not included, so external fusing on the input side is recommended.

Highlights

  • Wide input range 9 V to 36 V suits many DC sources
  • Fixed 12 V output at up to 5 A delivers 60 W
  • Conversion efficiency above 90 % keeps heat low
  • IP67 rated aluminium shell resists water dust and shock
  • Over-current and over-temperature protection guards connected equipment

Specifications

BrandDROK
ColorAluminium Shell
Weight0.109 kilograms

Questions about this item

How can I confirm the converter is working correctly after wiring it up?

Measure the output with a multimeter; it should read 12 V DC under load, and the aluminium shell should stay only warm thanks to the >90 % efficiency.

What comes in the package and what must I source separately?

The box contains one DC-DC stabiliser module; you must supply your own input and output wiring, connectors and a suitable 9–36 V DC source.

Which input voltage version should I select for a 24 V vehicle system?

The single module accepts 9 V, 12 V, 24 V and 36 V inputs, so the same unit covers a 24 V system without any model change.
