Rectangular aluminium module with mounting ears, IP67 rated

KEHIPI

KEHIPI 9-36V to 12V 3A 36W IP67 Power Adapter

SKU CH-XJ14-EMW3V

Converts 9-36V DC input to a stable 12V 3A output with IP67 waterproofing and over 90% efficiency

  • ColorAluminium Shell
  • Weight0.1 kilograms
  • Converts 9-36 V input to stable 12 V output for versatile installations
  • Delivers 3 A at 36 W to power displays, audio and solar gear
  • Over 90 % conversion efficiency keeps heat low during continuous operation
  • IP67 potted aluminium shell resists water, dust and shock in harsh environments
  • Built-in over-current and over-temperature protection safeguards connected equipment

Purpose and audience

The KEHIPI 9-36V to 12V 3A 36W IP67 Power Adapter is a DROK DC-DC converter that accepts an input range of DC 9V to 36V and delivers a fixed 12V output at up to 3A. It is intended for installers who need to power 12V equipment such as car audio, LCD televisions, LED display screens or solar power systems from a variable DC source.

Installation and common issues

The module measures 2.24*1.54*0.87 inch and uses 0.16 inch mounting ears for secure fitting in vehicles, outdoor enclosures or underground locations. Wiring must follow the supplied diagram exactly; short, thick cables are required to minimise voltage drop and the ground wires may be tied together because the unit is non-isolated. Short-circuit protection is not included, so external fusing is essential and loads must not be combined on a single output wire.

Who this suits and who should look elsewhere

The IP67 rated aluminium shell provides waterproof, dust-proof and shock-proof operation from -25 to 65 degrees Celsius, suiting mobile and harsh-environment installations. Builders who need galvanic isolation between input and output, short-circuit protection built in, or an output voltage other than 12V should consider a different converter.

Highlights

  • Converts 9-36 V input to stable 12 V output for versatile installations
  • Delivers 3 A at 36 W to power displays, audio and solar gear
  • Over 90 % conversion efficiency keeps heat low during continuous operation
  • IP67 potted aluminium shell resists water, dust and shock in harsh environments
  • Built-in over-current and over-temperature protection safeguards connected equipment

Specifications

BrandDROK
Model200664
ColorAluminium Shell
Weight0.1 kilograms

Questions about this item

How can I verify the KEHIPI 9-36V to 12V 3A 36W IP67 Power Adapter is working correctly after installation?

Measure the output with a multimeter under load; it should read 12V with no more than ±3% deviation, and the unit should stay cool thanks to over 90% conversion efficiency.

What comes in the box with the KEHIPI 9-36V to 12V 3A 36W IP67 Power Adapter, and what must I source separately?

The package includes one DC-DC stabiliser module only; you must supply your own input and output wiring, keeping leads short and thick to meet the 3A current rating.

Which version of the KEHIPI 9-36V to 12V 3A 36W IP67 Power Adapter should I choose for a 24V vehicle system?

The single model (MPN 200664) accepts 9-36V input, so it covers 12V and 24V systems directly; select it when your source voltage falls anywhere in that range.
