Two small green circuit boards with USB-C ports and screw terminals, side by side

KEHIPI

KEHIPI 2PCS 100W 5A USB-C PD QC Adjustable Voltage Power Trigger Module 5V 9V 12V 15V 20V Type-C Female Input

SKU CH-AS47-S8KKZ

Adjustable USB-C trigger module delivers up to 100 W at 5 V, 9 V, 12 V, 15 V or 20 V with PD and QC support

  • ColorType-C Female -Terminal Output
  • Adjustable 5V to 20V output for flexible device charging
  • Supports PD 3.0 and QC 3.0 for broad fast-charge compatibility
  • Button lock prevents accidental voltage changes that could damage equipment
  • Dual-module pack simplifies multi-port or redundant power setups
  • Rated for 100 W maximum power delivery with 5 A current capacity

Two-Pack USB-C PD Trigger Modules

This pair of trigger modules lets engineers and hobbyists extract adjustable voltage from any USB-C Power Delivery or Quick Charge source. Each board negotiates 5 V, 9 V, 12 V, 15 V or 20 V at up to 5 A, delivering a maximum of 100 W for bench testing, prototype power or portable equipment.

Terminal Output with Button Lock

The Type‑C female input uses integrated moulding for a secure connection, while screw terminals give a firm wire attachment for permanent or temporary builds. A front‑panel button locks the selected voltage to prevent accidental changes, and LEDs show the active output level at a glance.

Low-Quiescent Operation Up to 100 W

The modules draw minimal standby current and can sustain 20 V 5 A output when the connected supply allows, with built‑in protection rated above 30 V. Automated test modes such as voltage polling and cycling support ageing runs, while the last setting is restored automatically on power‑up.

Highlights

  • Adjustable 5V to 20V output for flexible device charging
  • Supports PD 3.0 and QC 3.0 for broad fast-charge compatibility
  • Button lock prevents accidental voltage changes that could damage equipment
  • Dual-module pack simplifies multi-port or redundant power setups
  • Rated for 100 W maximum power delivery with 5 A current capacity

Specifications

BrandAITRIP
ColorType-C Female -Terminal Output

Questions about this item

What USB-C power-delivery standards does the KEHIPI trigger module negotiate?

The module negotiates PD2.0, PD3.0, QC2.0, QC3.0 and AFC, then outputs 5V, 9V, 12V, 15V or 20V at up to 5A depending on the connected charger.

What physical connections are required to mount and wire the module?

A Type-C female port accepts the charger; two screw terminals on the board take the output wires for the load.

How do I set a fixed voltage and avoid accidentally changing it later?

Press the onboard button to cycle through 5V, 9V, 12V, 15V and 20V; the LED shows the active level and the button-lock feature prevents further changes until unlocked.
