Oval white wireless keypad with backlit buttons, IP54 rated, 85 by 75 by 35 mm

Jedrek

Jedrek 433.92 MHz 2-Channel Wireless Keypad Relay Switch HCS101

SKU CH-8VFQ-NW34A

Wireless keypad activates gates via 433.92 MHz rolling-code signal with IP54 rating and up to 200 m outdoor range

  • TypeKeyless Entry System
  • Wireless keyless entry for gates and doors
  • HCS101 rolling-code security on 433.92 MHz frequency
  • IP54 rated for indoor and outdoor mounting
  • Up to 200 m range outdoors and 35 m indoors
  • Two CR2032 batteries rated for two years at 10 daily uses

Wireless keypad for gate access

The Jedrek 433.92 MHz 2-Channel Wireless Keypad Relay Switch HCS101 provides keyless entry for gates and doors. It transmits a rolling code on the 433.92 MHz frequency using the HCS101 standard format. The unit suits homeowners or small businesses wanting a simple wireless access point without wiring a keypad to the controller.

IP54 oval enclosure for wall mounting

The oval housing measures 80.5 mm tall, 70.5 mm wide and 30.5 mm deep and carries an IP54 rating for indoor or outdoor installation. Signal range is quoted as 40 m in open space and 15 m indoors, while the technical data also lists 200 m outdoors and 35 m indoors. A backlight activates only while buttons are pressed to conserve the two CR2032 lithium cells.

Battery life and transmitter management

Two CR2032 3 V batteries (230 mAh each) are rated for roughly two years at ten activations per day. Battery polarity is marked with negative to the front and positive to the rear. The external receiver can erase all paired transmitters by holding its learn button until the indicator light turns off, simplifying access changes when a code is lost or a remote is misplaced.

Highlights

  • Wireless keyless entry for gates and doors
  • HCS101 rolling-code security on 433.92 MHz frequency
  • IP54 rated for indoor and outdoor mounting
  • Up to 200 m range outdoors and 35 m indoors
  • Two CR2032 batteries rated for two years at 10 daily uses

Specifications

TypeKeyless Entry System

Questions about this item

What range does the 433.92 MHz keypad achieve outdoors and indoors?

The keypad reaches about 40 metres in open space and roughly 15 metres inside buildings.

What are the exact dimensions and IP rating for mounting this oval keypad?

It measures 80.5 mm tall, 70.5 mm wide and 30.5 mm deep with an IP54 rating for indoor or outdoor wall mounting.

How do I pair the keypad with the receiver and which battery orientation is correct?

Press the receiver's learn button, enter your code on the keypad, then fit one CR2032 cell with the negative side facing the front and positive to the rear.
