Black rectangular 8x8 HDMI matrix switcher with front panel indicators

Jansicotek

Jansicotek OZJ8 8x8 HDMI 2.0b Matrix Switcher

SKU CH-89FC-XNARM

An 8×8 HDMI 2.0b matrix routes eight 4K@60 Hz sources to eight displays with 18 Gbps bandwidth, HDCP 2.2, HDR10 and RS-232 control

  • TypeHDMI Switchers
  • Changer TypeHDMI Switch/Extender
  • ColorBlack
  • Ports8x8 Matrix
  • MatrixYes
  • AudioYes
  • Routes 8 sources to 8 displays independently
  • 4K 60 Hz 4:4:4 RGB 18 Gbps bandwidth
  • HDCP 2.2 and HDR10 content protection
  • IR remote, RS-232 and front-panel control
  • Compact 5.91 × 2.36 × 0.79 in enclosure

8x8 HDMI 2.0b Matrix Switcher

The Jansicotek OZJ8 routes up to eight 4K HDR sources to eight displays or projectors. It suits AV integrators and multi-room installations that need flexible signal distribution without a dedicated processor. Buyers who want more than eight inputs or outputs cannot use this unit.

Build quality and daily connectivity

A black metal chassis measures 5.91 by 2.36 by .79 inches and weighs 11.9 ounces. Front-panel keys, an IR remote, and an RS232 port give three ways to switch sources on the fly. Input cables must stay under 8 metres using AWG26 HDMI 2.0b leads; longer runs are not supported.

Practical limits of the HDMI 2.0b interface

The switch passes 18Gbps bandwidth with a 600MHz TMDS clock and handles 3840 x 2160 at 60Hz in RGB888 or YUV444. Deep colour up to 24-bit, 3D formats, and HDCP2.2 are included. Resolutions above 4096 x 2160 or refresh rates beyond 60Hz at 4K exceed the interface capability.

Highlights

  • Routes 8 sources to 8 displays independently
  • 4K 60 Hz 4:4:4 RGB 18 Gbps bandwidth
  • HDCP 2.2 and HDR10 content protection
  • IR remote, RS-232 and front-panel control
  • Compact 5.91 × 2.36 × 0.79 in enclosure

Specifications

BrandJansicotek
SeriesOZJ8
ModelOZJ8
Part NumberOZJ8
TypeHDMI Switchers
Changer TypeHDMI Switch/Extender
ColorBlack
Ports8x8 Matrix
MatrixYes
AudioYes
SpecificationsHDMI version: HDMI 2.0b
HDMI resolution: Up to 3840*2160@60Hz; YUV(4:4:4) RGB.
Support video format: 3D, 8/ 10/ 12/ 24 bit deep color.
Max bandwidth: 600MHz
Max band rate: 18Gbps
Input cable distance: less than 8m AWG26 HDMI 2.0b standard cable
Output cable distance: less than 8m AWG26 HDMI 2.0b standard cable
HDMI Matrix Ports: 8*HDMI Input; 8*HDMI Output; 1*RS232 Port; 1*DC 12V Power Port
Switching mode: Manual switching & IR remote control switch
Power adapter format: Input: AC (50HZ, 60HZ) 100V-240V; Output: DC 12V/2A
Max working current: 500mA
Input Connector8 x HDMI
Output Connector8 x HDMI
Maximum Cable Lengthless than 8m AWG26 HDMI 2.0b standard cable
Maximum Resolutions4096 x 2160
Bandwidth18Gbps/600MHZ
Features8 HDMI Input 8HDMI Output: This 8X8 HDMI Matrix routes up to eight 4K HDR HDMI sources to eight 4K HDR display devices. can be used for multiple high-definition digital video inputs and outputs exchange; any one of the signal outputs can be selected from any one of the signal sources without interfering with other outputs.
4K 60Hz Support & Downscale Function: Supports up to 4K 60Hz resolution with support for HDR,3D.Enjoy UHD content as it was intended.And the device supports mixed 4K & 1080p display ports. Each output supports downscale functionality, it can display 4K or downscale
Dimensions5.91 x 2.36 x 0.79 inches
Weight11.9 ounces
Package Quantity1
Package Contents1x HDMI Matrix 8x8
1x 12V power adapter
1x IR Remote Control
1x User Manual

Questions about this item

What does the HDMI 2.0b interface cap at for 4K HDR signals?

The HDMI 2.0b interface supports up to 3840×2160 at 60 Hz with YUV 4:4:4 RGB and 18 Gbps bandwidth, and it carries HDCP 2.2 and HDR10 for protected 4K HDR content.

What rack space and cabling does the unit need to fit?

The chassis measures 5.91 by 2.36 by 0.79 inches and weighs 11.9 ounces; it accepts eight HDMI inputs and eight HDMI outputs with cables no longer than 8 metres using AWG 26 HDMI 2.0b standard leads.

How is the matrix configured, and which step do installers often miss?

Connect sources and displays, then use the front-panel keys, IR remote, or RS-232 commands to route each input to the desired output; the step often missed is sending the explicit routing command for every output after power-up, as the unit does not default to a one-to-one map.
