Aqua blue Mini SAS SFF-8087 to four SATA breakout cable 1.5 ft

JacobsParts Inc.

JacobsParts Inc. Mini SAS SFF-8087 to 4 SATA Breakout Cable 1.5 ft Aqua Blue

SKU CH-PWSQ-6W0HX

Connects a RAID or PCIe controller with an SFF-8087 port to four SATA drives at up to 6Gbs per drive

  • TypeSATA III
  • ColorAqua Blue
  • Length1.5 ft.
  • Connector Number4
  • StyleSAS32PIN-4XSATA7PIN
  • Connect RAID or PCIe controllers to four SATA drives via SFF-8087
  • Achieve 6 Gb/s transfer speed per drive with SATA III support
  • Flexible 1.5 ft aqua blue cable with woven mesh sheath for easy routing
  • Low-profile SATA connectors with steel latches prevent accidental disconnection
  • Two cables enable up to eight drives across PCIe 2.0 x8 lanes

Internal Storage Cable

The JacobsParts Mini SAS breakout cable links a RAID or PCIe controller equipped with an SFF-8087 port to four SATA drives. It supports up to 6Gbs per drive and measures 1.5 ft with an aqua blue woven sheath.

Server Builders and Storage Expansion

This cable suits administrators adding direct-attached SATA storage to a host bus adapter with a 32-pin mini SAS connector. It is not suited for external enclosures or for connecting drives without a SATA interface.

32-Pin SFF-8087 Connector

The single specification that decides compatibility is the 32-pin SFF-8087 connector on the controller side. Your host adapter must present this exact port for the cable to function.

Highlights

  • Connect RAID or PCIe controllers to four SATA drives via SFF-8087
  • Achieve 6 Gb/s transfer speed per drive with SATA III support
  • Flexible 1.5 ft aqua blue cable with woven mesh sheath for easy routing
  • Low-profile SATA connectors with steel latches prevent accidental disconnection
  • Two cables enable up to eight drives across PCIe 2.0 x8 lanes

Specifications

TypeSATA III
ColorAqua Blue
Length1.5 ft.
Connector Number4
StyleSAS32PIN-4XSATA7PIN

Questions about this item

Should I pick the 1.5 ft or 1.6 ft version of this breakout cable?

Both figures describe the same cable; the 1.5 ft label is the rounded spec and 1.6 ft is the exact 50 cm length, so there is no separate version to choose.

Will the 6Gbs per-drive rate actually be reached inside my server?

Each SATA drive can run at up to 6Gbs, but the four lanes share the host controller's PCIe 2.0 x8 bandwidth, so sustained throughput depends on the controller and drive mix.

Does the SFF-8087 end limit me to a specific SAS generation?

The SFF-8087 connector carries four 6Gbs lanes, matching the cable's rated 6Gbs per drive; it does not impose a lower ceiling than the drives themselves.
