Black 4U rackmount chassis with aluminium front bezel and 20 inch sliding rails

iStarUSA Inc.

iStarUSA Inc. D-400SEA-BK-RAIL24 4U server rack with 20" sliding rails

SKU CH-TYSR-EGHZ3 MPN D-400SEA-BK-RAIL24

4U rackmount chassis with aluminium front bezel, 120 mm and 80 mm fans, seven expansion slots and 20" sliding rails

  • TypeRack Mount Cabinet
  • Rack Units4U
  • ColorColor of Front Bezel: Black Color of Main Chassis: Black
  • MaterialMaterial of Front Bezel: Aluminum alloy Material of Handle:
  • Cooling (Optional)1 x 80mm
  • Cooling (Standard)1 x 80mm, 1 x 120mm
  • 4U rack height fits standard cabinets
  • Patented aluminium front bezel with key lock secures hardware
  • One 120 mm and one 80 mm fan provide standard cooling
  • Four 5.25" and three 3.5" drive bays support mixed storage
  • 20-inch sliding rail kit eases installation and service

4U rackmount chassis with sliding rails

The iStarUSA D-400SEA-BK-RAIL24 is a 4U rackmount cabinet built from 1.2mm SECC zinc-coated steel with an aluminium alloy front bezel. It ships with a 20" sliding rail kit for quick installation in standard 19" racks. The unit suits small-server deployments and test-lab builds that need front-panel security and compact depth.

Fits ATX or microATX boards with seven expansion

The chassis accepts motherboards up to 12" x 9.6" and provides seven rear expansion slots for add-in cards. A PS2 or mini-redundant power supply is required but not included. One 120 mm and one 80 mm fan are pre-installed; an optional second 80 mm fan can be added. Four 5.25" bays, one external 3.5" bay and two internal 3.5" bays handle mixed storage layouts.

Locking bezel, front USB and status LEDs

The patented aluminium front panel includes a key lock to restrict physical access. Two front USB 2.0 ports allow quick peripheral connection. Power, reset, HDD, temperature and fan indicators are built in; temperature and fan readings need the optional TC-ISF08 sensor board. An optional BPU-230 cage converts two internal 3.5" bays into three hot-swappable slots.

Highlights

  • 4U rack height fits standard cabinets
  • Patented aluminium front bezel with key lock secures hardware
  • One 120 mm and one 80 mm fan provide standard cooling
  • Four 5.25" and three 3.5" drive bays support mixed storage
  • 20-inch sliding rail kit eases installation and service

Specifications

BrandiStarUSA
ModelD-400SEA-BK-RAIL24
TypeRack Mount Cabinet
Rack Units4U
ColorColor of Front Bezel: Black
Color of Main Chassis: Black
MaterialMaterial of Front Bezel: Aluminum alloy
Material of Handle: SECC Zinc-Coated Steel
Material of Main Chassis: 1.2mm SECC Zinc-Coated Steel (Japan Made)
Cooling (Optional)1 x 80mm
Cooling (Standard)1 x 80mm, 1 x 120mm
SpecificationStandard Drive Bays:
- 3.5" Drives: 1
- 3.5" Drive (internal): 2
- 5.25" Drives: 4
Indicators: Power, HDD, Temperature, Fan (Fan/Temp require sensor board TC-ISF08 )
Switches: Power, Reset
Supported PSU Type: PS2, Mini Redundant
Expansion Slots: 7
Security: Front Bezel Key Lock
Front Connector: 2 x USB 2.0
Motherboard Size: 12" x 9.6" (ATX, microATX)
FeaturesPatented Aluminum Front Panel with Locks
Optional BPU-230 2 to 3 Hot-Swappable HDD Cage
Optional Aluminum Chassis
Power and Alarm Reset Switch
Power and HDD LED
Front Access USB2.0 x2
120mm x1 and 80mm x1 Cooling Fan
with 20" Sliding Rail Kit
Unit Dimension19.00" x 7.00" x 20.80"
Shipping weight18.14 kg
Package size686 × 559 × 305 mm

Questions about this item

How many drive bays can I fill before I run out of internal 3.5" slots?

The chassis provides two internal 3.5" drive bays, so the third 3.5" drive must use the single external bay.

What is the combined airflow of the standard 120 mm and 80 mm fans during continuous operation?

One 120 mm fan and one 80 mm fan are included as standard; an optional second 80 mm fan can be added for extra airflow.

Which power supply form factor must I already have to fit this 4U chassis?

The rackmount cabinet accepts PS2 or mini-redundant power supplies only.
