Aqua duplex fiber patch cable with LC connectors on both ends, 2 m length

Intellinet Network Solutions

Intellinet Network Solutions OM4 Multimode Duplex LC-LC 2 m Aqua 50/125 µm BIMMF

SKU CH-V4JE-H9S1R

A 2 m aqua duplex LC-LC patch cable with OM4 50/125 µm bend-insensitive multimode fiber for 10, 40 and 100 G Ethernet links

  • TypeFiber
  • Connector ALC
  • Connector BLC
  • Length2 m
  • ColorAqua Blue
  • ShieldedNo
  • OM4 multimode fiber supports 10G, 40G and 100G Ethernet speeds
  • UPC connectors provide improved return loss for better signal quality
  • Bend-insensitive design reduces attenuation when cables are bent or twisted
  • Corning ultra-pure glass fiber delivers low attenuation and high bandwidth
  • 2 m aqua duplex LC-LC patch cable for data center interconnects

Ideal for Data Centre Interconnects

This duplex fibre patch cable uses OM4 multimode glass with a 50/125 µm core and LC/UPC connectors at both ends. The aqua jacket identifies the cable as OM4 and suits cross-connect or interconnect work in entrance facilities, telecommunications rooms and data centres. Each unit ships with its own test report.

Upgrades OM3 Links for 40G and 100G Ethernet

The OM4 specification raises modal bandwidth so that 40G and 100G Ethernet runs become practical over the same short-to-medium distances where OM3 would fall short. If an existing installation already uses OM3 and runs only 10G, the extra cost of OM4 will not be recovered.

Straightforward LC-to-LC Installation

Connectors are pre-terminated and polished to UPC standard, so the link is ready to plug into any LC port without field splicing or polishing. The 2.0 mm bend-insensitive jacket tolerates tight routing, but the cable is not shielded and must not be run in plenum spaces that require OFNP rating.

Highlights

  • OM4 multimode fiber supports 10G, 40G and 100G Ethernet speeds
  • UPC connectors provide improved return loss for better signal quality
  • Bend-insensitive design reduces attenuation when cables are bent or twisted
  • Corning ultra-pure glass fiber delivers low attenuation and high bandwidth
  • 2 m aqua duplex LC-LC patch cable for data center interconnects

Specifications

BrandIntellinet Network Solutions
ModelOM4 Multimode Duplex
TypeFiber
Connector ALC
Connector BLC
Length2 m
ColorAqua Blue
ShieldedNo
Features50/125 µm, Bend Insensitive Multimode Fiber (BIMMF), UPC

Questions about this item

Will the 2.0 mm duplex jacket fit standard LC patch panels?

The 2.0 mm duplex jacket fits standard LC patch panels and cable-management trays.

What is the correct way to seat the UPC ferrules so return loss stays low?

Push each LC connector straight in until the latch clicks; angled insertion can chip the UPC polish and raise return loss.

When should the cable be replaced based on the included test report?

Re-test with an OTDR or loss-test set annually; replace if insertion loss exceeds the original report values or if the aqua jacket shows kinks or cracks.
