Flat-pack 19 inch 6U wallmount server rack steel frame black tempered glass door

Intellinet Network Solutions

Intellinet Network Solutions 711715 19" 6U Wallmount Server Rack 450mm Depth Flat Pack Black

SKU CH-9P56-287RE MPN 711715

A 19-inch, 6U wall-mount server rack with 450 mm depth, tempered-glass door opening beyond 180°, reversible front, removable side panels, and 132 lb load capacity

  • TypeRack Cabinet
  • Rack Units6U
  • ColorBlack
  • MaterialSteel
  • Weight Capacity132 lbs
  • Included Accessory2 depth-adjustable mounting rails, tool, M6 nuts, two keys
  • 6U wall-mount cabinet fits 19" rack gear
  • 132 lb static load on 1.2 mm steel frame
  • Adjustable 270–350 mm usable depth for varied hardware
  • Tempered-glass door swings past 180° for full access
  • Flat-pack 450 mm deep unit ships compact and assembles fast

19" 6U Wallmount Cabinet for Network Gear

This 19-inch, 6U steel cabinet mounts on a wall and holds rack-mount network equipment up to 132 lbs. It ships flat-packed and includes two depth-adjustable rails, M6 nuts, a tool and two keys for the tempered-glass front door. The reversible door opens past 180 degrees for full access.

Usable Depth Limits and Cable Entry

Adjustable rails provide a usable depth between 270 mm and 350 mm inside the 450 mm deep frame. Cable entry is available through the rear panel or the top panel. The cold-rolled, galvanized SPCC steel construction uses material up to 1.2 mm thick to support the rated static load of 60 kg.

Replaces Open-Frame Racks When Security

The lockable glass door and removable side panels secure equipment while allowing quick service access. It upgrades basic open racks by adding physical security and dust resistance in the same wall footprint. Not suited for deep servers exceeding the 350 mm maximum rail depth or for installations requiring forced-air cooling beyond passive ventilation.

Highlights

  • 6U wall-mount cabinet fits 19" rack gear
  • 132 lb static load on 1.2 mm steel frame
  • Adjustable 270–350 mm usable depth for varied hardware
  • Tempered-glass door swings past 180° for full access
  • Flat-pack 450 mm deep unit ships compact and assembles fast

Specifications

BrandIntellinet
TypeRack Cabinet
Rack Units6U
ColorBlack
MaterialSteel
Weight Capacity132 lbs
Included Accessory2 depth-adjustable mounting rails, tool, M6 nuts, two keys
Shipping weight15.42 kg
Package size605 × 419 × 203 mm

Questions about this item

Should I choose the flat-pack 6U cabinet or an assembled alternative?

This model ships unassembled in a flat pack; assembled versions exist in some regions but are a separate SKU, so pick flat-pack if you want lower shipping volume or assembled if you prefer to skip the build step.

What does the 132 lb static load rating mean once the rack is on the wall?

The 60 kg (132 lb) rating is the maximum weight the welded SPCC steel frame can hold when mounted to a solid wall with appropriate fixings; it covers the combined weight of all installed equipment.

How does the 19-inch standard limit what I can mount inside?

The EIA 19-inch spacing accepts any rack-mount gear with standard hole patterns; depth is the real constraint — adjustable rails provide 270 mm to 350 mm usable depth, so measure your deepest device before buying.
