Black QSFP+ passive DAC twinax cable, 10 ft, 30 AWG

Intellinet Network Solutions

Intellinet Network Solutions 508537 QSFP+ 40G Passive DAC Twinax Cable 10 ft 30 AWG Black

SKU CH-RT8K-J5EMR MPN 508537

Passive QSFP+ DAC twinax cable delivers 40 Gbps over 10 ft with under 0.15 W draw

  • Length10 ft.
  • ColorBlack
  • Wire Gauge30 AWG
  • Cost-effective 40 Gbps connectivity with passive copper design
  • MSA-compliant QSFP+ ends work with Cisco, Ubiquiti, TP-Link switches
  • Under 0.15 W draw cuts data-centre operating costs
  • 10 ft twinax reaches 23 ft max for short-range links
  • Simpler deployment than fibre — no transceivers to match

QSFP+ 40 Gbps passive DAC cable

This passive Direct Attach Copper twinax cable uses QSFP+ connectors on both ends to deliver 40 Gbps links with near-zero power draw and latency lower than RJ45. It is built for short-range structured cabling between switches, routers, servers and storage in top-of-rack or adjacent-rack layouts up to 7 m. The 10 ft length and 30 AWG conductors suit rack-to-rack runs inside a single cabinet or between neighbouring racks. MSA compliance keeps it compatible with a broad range of network equipment.

Suits short-haul 40 GbE links; not for longer runs

Network teams needing cost-effective, low-latency 40 GbE connections inside a rack or to an adjacent rack will benefit from the passive design that consumes less than 0.15 W and operates up to 70 °C. Buyers who need reaches beyond 7 m or who require optical isolation for EMI-sensitive environments should look at active optical or fiber solutions instead. The cable is not intended for outdoor, plenum or extended-distance deployments.

10 ft 30 AWG passive twinax with dual QSFP+

The single specification that decides fit is the 10 ft passive twinax construction rated for 40 Gbps over QSFP+ ends. At 30 AWG it supports the stated 7 m maximum for passive DAC, so verify that your rack-to-rack distance stays within that limit. If the link exceeds 7 m or your switch ports require active cables, this part will not work.

Highlights

  • Cost-effective 40 Gbps connectivity with passive copper design
  • MSA-compliant QSFP+ ends work with Cisco, Ubiquiti, TP-Link switches
  • Under 0.15 W draw cuts data-centre operating costs
  • 10 ft twinax reaches 23 ft max for short-range links
  • Simpler deployment than fibre — no transceivers to match

Specifications

Length10 ft.
ColorBlack
Wire Gauge30 AWG
Shipping weight0.26 kg
Package size312 × 249 × 18 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Do I need two QSFP+ ports on my equipment for this 40 Gbps DAC cable to work?

Yes, the cable has QSFP+ connectors on both ends and requires a matching QSFP+ port on each device to achieve 40 Gbps data transfer.

Will this passive twinax cable work with my existing 40GbE switches from Cisco or Ubiquiti?

The cable is MSA-compliant and designed for compatibility with leading manufacturers including Cisco, Ubiquiti, TP-Link, ZyXEL and Intellinet Network Solutions switches.

How can I confirm the link is running at the full 40 Gbps after I connect the cable?

Check the port status on each switch or router; it should show a 40 Gbps link with no errors, and the connection will consume less than 0.15 W of power.
