Black armored Ethernet cable with stainless steel jacket and RJ45 connectors, 5 ft length

InstallerParts Cat6A Armored Patch Cable 24AWG 7.8mm 5 Ft

SKU CH-A9BM-RENW2

Stainless-steel armored Cat6A patch cable rated for 10 Gbps at 550 MHz with waterproof, UV-resistant jacket for outdoor and industrial use

  • TypeCAT6A
  • Cat6A
  • Connector ARJ45
  • ColorBlack
  • Features, , , ,
  • Armored SUS304 stainless steel jacket protects against physical damage, moisture, UV and corrosion
  • Cat6A rated 550 MHz bandwidth delivers up to 10 Gbps for cloud storage, video conferencing and streaming
  • 24 AWG pure copper conductors with 50 micron gold-plated RJ45 plugs maintain signal integrity up to 150 Ft
  • Waterproof, UV-resistant design built for outdoor, factory automation, warehouse and harsh environments
  • TIA/EIA T-568B wiring, UL Listed and RoHS certified for broad device compatibility

Armoured Cat6A patch cable for harsh environments

This five-foot Cat6A patch cable uses a SUS304 stainless-steel flexible jacket to shield the 24 AWG conductors from moisture, UV exposure and physical damage. It is built for factory automation, warehouse, outdoor and other harsh-condition installations where standard jackets would degrade. The 7.8 mm diameter armour adds mechanical protection without sacrificing the 10 Gbps bandwidth rating.

Practical limits of the Cat6A 550 MHz standard

Cat6A supports up to 10 Gbps over 100 metres, but the supplier notes signal integrity is maintained on this 24 AWG construction for runs up to 150 feet. The cable is terminated to the TIA/EIA 568B wiring scheme and carries UL listing and RoHS certification. Shielded RJ45 plugs with 50 micron gold contacts preserve performance in noisy industrial or PoE environments.

Check connector clearance

The 7.8 mm armoured jacket is significantly thicker than standard patch cables, so verify that your panel ports, cable managers and conduit entries accept the larger diameter. Ensure the routing path can accommodate the bend radius of the stainless-steel sheath and that the RJ45 plug body fits any recessed or high-density ports on switches, servers or outdoor enclosures.

Highlights

  • Armored SUS304 stainless steel jacket protects against physical damage, moisture, UV and corrosion
  • Cat6A rated 550 MHz bandwidth delivers up to 10 Gbps for cloud storage, video conferencing and streaming
  • 24 AWG pure copper conductors with 50 micron gold-plated RJ45 plugs maintain signal integrity up to 150 Ft
  • Waterproof, UV-resistant design built for outdoor, factory automation, warehouse and harsh environments
  • TIA/EIA T-568B wiring, UL Listed and RoHS certified for broad device compatibility

Specifications

BrandInstallerParts
TypeCAT6A
Cat6A
Connector ARJ45
ColorBlack
Features, , , ,

Questions about this item

Should I pick the 24AWG 7.8mm or the 28AWG 4.9mm version?

The 24AWG 7.8mm cable uses thicker conductors that maintain signal integrity up to 150ft, while the 28AWG 4.9mm variant is thinner and more flexible for tight indoor routing.

What does the 10 Gbps rating actually deliver on my network?

The Cat6A specification supports 10 Gbps throughput at 550 MHz bandwidth, enabling full 10 Gigabit Ethernet speeds for cloud storage, video conferencing and streaming when connected to compatible 10G ports.

How does the RJ45 TIA/EIA 568B wiring limit what I can plug in?

The T-568B pinout is the standard LAN wiring used by virtually all routers, switches, PCs and servers, so the cable connects directly without crossover adapters or special configuration.
