Small black network adapter with two RJ45 ports and a DC power jack

Inscape Data Corporation

Inscape Data Corporation PS1060-24 802.3bt 24V 60W Gigabit Splitter adapter

SKU CH-KSR3-SPV1Z

Splits 802.3bt 56V PoE into 24V 60W DC while passing gigabit data through two RJ45 ports

  • Delivers 24V 60W DC power from 56V 802.3bt PoE source
  • Splits high-power PoE for IP PTZ cameras and IR illuminators
  • Two Gigabit RJ45 ports support 10/100/1000Mbps network speeds
  • Fanless natural cooling ensures silent desktop or wall-mount operation
  • Built-in lightning protection on power input enhances installation safety

24V 60W PoE Splitter for IP Cameras

The Inscape Data PS1060-24 splits IEEE 802.3bt high-power PoE from a 56V source into regulated 24V 60W DC output. It provides two Gigabit RJ45 ports for data pass-through and device connection. The unit is designed for high-power PTZ cameras and IR illuminators requiring 24V input. Silent fanless cooling suits desktop or wall placement.

Replaces Separate Injector and Converter

This adapter combines PoE splitting and voltage conversion in one device, removing the need for a separate 56V injector plus a DC-DC step-down module. The jump is worth it when deploying 24V cameras over existing 802.3bt infrastructure up to 60W. It supports both mid-span and end-span pinouts for broad switch compatibility. Lightning-protected input adds resilience on outdoor runs.

Plug-and-Play with Pinout Attention

Installation requires only connecting the PoE source to the input port and the camera to the output port; no software configuration is needed. The main issue is verifying that the upstream switch or injector delivers 802.3bt Class 6 or higher power. Mismatched pinout selection between mid-span and end-span will prevent power delivery. Ensure the 24V device does not exceed the 60W limit.

Highlights

  • Delivers 24V 60W DC power from 56V 802.3bt PoE source
  • Splits high-power PoE for IP PTZ cameras and IR illuminators
  • Two Gigabit RJ45 ports support 10/100/1000Mbps network speeds
  • Fanless natural cooling ensures silent desktop or wall-mount operation
  • Built-in lightning protection on power input enhances installation safety

Specifications

No published specifications for this item yet.

Questions about this item

What size Ethernet cable and PoE standard does the PS1060-24 require for the 60 W 24 V output?

The splitter accepts a Cat5 cable carrying IEEE 802.3bt power from a 56 V source and delivers 24 V 60 W DC to the device.

Which RJ45 port should the PoE injector connect to, and what wiring modes are supported?

Connect the injector to the single high-power PoE port; the unit handles both mid-span (4/5+, 7/8-) and end-span (1/2+, 3/6-) wiring.

Does the fanless PS1060-24 need any periodic cleaning or component replacement?

No moving parts are present, so only occasional dust removal from the vents is required to maintain natural cooling.
