Small rectangular network adapter with two RJ45 ports and a matte metal finish

Inscape Data Corporation

Inscape Data Corporation LinkPower PE1025 PoE Extender

SKU CH-F189-2C00F

Extends PoE connections from 100 to 200 metres over Cat5e cable while delivering up to 25.5 W to powered devices

  • Doubles PoE cable reach to 200 metres via Cat5e/6
  • Delivers up to 25.5 W through a single RJ45 port
  • Works with any IEEE 802.3af/at power sourcing equipment
  • Plug-and-play operation with no extra power supply needed
  • Auto-negotiation and auto-MDIX simplify 10/100/1000 Mbit connections

Product identity

The Inscape Data LinkPower PE1025 is a single-port Gigabit PoE extender that pushes Ethernet and power over Cat5e or Cat6 cable from 100 meters to 200 meters. It targets installers who need to reach cameras, access points or IoT nodes beyond the standard copper limit without adding a local power outlet.

Compatibility checklist

Verify that your power sourcing equipment complies with IEEE 802.3af or 802.3at and can deliver up to 25.5 watts on the port you will extend. Ensure the cabling run uses Cat5e or better UTP and that the total link does not exceed 200 meters. The unit requires no separate power supply or configuration.

Upgrade perspective

This extender replaces the need for a mid-span injector plus a second copper run or a fibre conversion kit when the only gap is distance. The jump is worth it when a single additional 100-meter segment solves the placement problem and the attached device draws 25.5 watts or less.

Highlights

  • Doubles PoE cable reach to 200 metres via Cat5e/6
  • Delivers up to 25.5 W through a single RJ45 port
  • Works with any IEEE 802.3af/at power sourcing equipment
  • Plug-and-play operation with no extra power supply needed
  • Auto-negotiation and auto-MDIX simplify 10/100/1000 Mbit connections

Specifications

No published specifications for this item yet.

Questions about this item

Does the PE1025 include any cables or a power adapter in the box?

The extender draws power over the Ethernet link, so no separate power supply is needed. Standard Cat5e or Cat6 patch cables are required to connect the two RJ45 ports.

How do I decide between the 25.5 W single-port limit and the 100 metre versus 200 metre reach?

One PE1025 adds a second 100 metre segment, giving 200 metres total while still delivering up to 25.5 W to a single PoE device.

What does the 25.5 W figure mean when the extender is installed in a live network?

It is the maximum PoE power the downstream port can supply to a camera, access point or other 802.3at device after the extender itself consumes its operating power.
