Green circuit board with U.2 connector and PCIe edge fingers

Innocard

Innocard PCIe Gen4 gender changer for U.2 SSD

SKU CH-VK6E-WCDV5

PCIe 4.0 x4 adapter converts U.2 SSD with hot-plug power, clock buffer and SMBus management for server BMC control

  • Changer TypePCIe Gen4
  • Converts U.2 SSD to PCIe 4.0 x4 for high-speed data transfer
  • Supports server BMC management enabling remote SSD monitoring and control
  • Industrial-grade temperature range ensures reliable operation in demanding environments
  • Built-in PCIe clock buffer drives longer traces and cables without signal loss
  • Dual 12 V hot-plug power with eFuse protection safeguards U.2 dual-port SSDs

PCIe Gen4 U.2 SSD adapter

This Innocard adapter converts a U.2 SFF-8639 solid-state drive to a PCI Express 4.0 x4 slot. It includes hot-plug controllers with dual 12 V eFuse-protected power outputs rated at 6.5 A each. The board is designed and manufactured in Taiwan for server and industrial environments.

Suits managed server and industrial builds

The integrated BMC support, out-of-band PERST# reset and wide temperature range make it a fit for managed server chassis and industrial systems that require remote drive control. Builds without a free PCIe x4 slot, without U.2 drives or without need for hot-plug management will not use the features this card provides.

Dual-port power and extended signal reach

On-board clock buffer, SMBus switch and I/O expander drive longer cable runs to remote U.2 bays. Each 12 V output uses a 32 mOhm NexFET with programmable current limit and thermal shutdown for reliable dual-port operation. The single x4 lane width sets the throughput ceiling for any attached drive.

Highlights

  • Converts U.2 SSD to PCIe 4.0 x4 for high-speed data transfer
  • Supports server BMC management enabling remote SSD monitoring and control
  • Industrial-grade temperature range ensures reliable operation in demanding environments
  • Built-in PCIe clock buffer drives longer traces and cables without signal loss
  • Dual 12 V hot-plug power with eFuse protection safeguards U.2 dual-port SSDs

Specifications

Changer TypePCIe Gen4

Questions about this item

Do I need a free PCI Express 4.0 x4 slot on my motherboard to use this adapter?

Yes, the adapter converts a U.2 SSD to a PCI Express 4.0 x4 interface, so an available x4 slot is required.

Will my existing U.2 SSD work with the built-in SMBus switch and I/O expander?

The adapter includes an SMBus switch at address 0x71 and an I/O expander at address 0x41 for PWRDIS control, compatible with standard U.2 drives.

How can I verify the hot-plug power circuits are active after installation?

The dual 12 V hot-plug controllers provide programmable current limits up to 6.5 A with fault alerts; check the system management console for power-good status.
