Innocard M.2 PCIe Gen 4 gender changer with ReDriver for SFF-TA-1002, SFF-TA-1020
Converts Gen-Z 1C EDSFF devices to PCIe 4.0 M.2 using a built-in ReDriver and clock buffer for 16 GT/s signal integrity over longer cables
- Changer TypePCIe Gen4
- Converts Gen-Z 1C EDSFF to PCIe 4.0 M.2 4-lane
- Built-in PCIe ReDriver extends 16GT/s signals over longer traces
- On-board 100MHz clock buffer drives extended cable lengths
- SMBCLK/SMBDAT bidirectional repeater maintains link integrity
- PERST# bus buffer gate supports longer trace and cable runs
Gen-Z 1C to M.2 PCIe 4.0 adapter
This adapter converts a Gen-Z 1C EDSFF connector to a four-lane PCI Express 4.0 M.2 slot. An onboard ReDriver extends 16 GT/s differential signals while a clock buffer and SMBus repeater maintain link integrity over longer traces. PERST# buffering supports extended cable runs in server and accelerator chassis.
Suits rack, tower and microserver builds
Engineers adding Gen-Z storage or accelerator cards to platforms with M.2 sockets will find the mechanical and electrical conversion handled in one module. Systems without a Gen-Z 1C edge connector or without space for the adapter length cannot use this part.
PCIe 4.0 ReDriver for 16 GT/s operation
The integrated ReDriver is the component that enables Gen 4 signal quality across the gender change. Without it, the 16 GT/s link would not meet the PCI Express Base Specification Rev 4.0 eye requirements over the combined connector and trace path.
Highlights
- Converts Gen-Z 1C EDSFF to PCIe 4.0 M.2 4-lane
- Built-in PCIe ReDriver extends 16GT/s signals over longer traces
- On-board 100MHz clock buffer drives extended cable lengths
- SMBCLK/SMBDAT bidirectional repeater maintains link integrity
- PERST# bus buffer gate supports longer trace and cable runs
Specifications
| Changer Type | PCIe Gen4 |
|---|
Questions about this item
What PCIe generation and signalling rate does the SFF-TA-1002/1020 gender changer support?
It complies with PCI Express Base Specification Rev 4.0 and the built-in ReDriver extends 16GT/s differential-pair signals across the Gen-Z 1C to M.2 conversion.
Which connectors and physical standards must the host and device match for this adapter to fit?
The adapter has a built-in Gen-Z 1C (EDSFF) connector on one side and converts to a PCIe 4.0 M.2 4-lane slot compliant with the M.2 Spec Rev 4.0 Ver 1.0.
What firmware or BIOS requirement is often missed when installing this gender changer in a server or desktop?
The system must run UEFI 2.3.1 or later; legacy BIOS without UEFI support will not initialise the PERST# and SMBus buffers correctly.
