Silver 2U rackmount server with twelve drive bays visible

IBM

IBM FlashSystem 5015 SAS HDD 20TB barebone server

SKU CH-RTX2-B2VY4 MPN FlashSystem 5015 SAS HDD 20TB

2U rackmount storage server with dual active controllers, 12 x 2.4TB 10K SAS drives, 64GB cache, 16Gb Fibre Channel and 1Gb iSCSI host connections

  • Form Factor2U Rackmount
  • WorkloadStorage Server
  • 2.5" BaysCapacity: up to 20TB Cache: 64GB Drive Configuration: 12 x 2
  • FeaturesData Reduction Pools (Compression, DeDuplication, Thin Provi

Option FlashSystem 5015 SAS HDD 20TB

  • 20TB raw capacity from twelve 2.4TB 10K SAS drives
  • 64GB cache accelerates read-intensive storage workloads
  • Dual active controllers deliver continuous availability
  • 16Gb Fibre Channel plus 1Gb iSCSI host connectivity
  • 400K IOPS with sub-70µs latency for demanding applications

IBM FlashSystem 5015 Storage Server

The IBM FlashSystem 5015 is a 2U rackmount storage server designed for enterprise workloads. It arrives with 12 x 2.4TB 10K SAS HDDs installed and a 64GB cache. Dual active controllers and redundant power supplies provide high availability.

Ideal For And Not For

Suits IT teams building a SAN with block access over 16Gb Fibre Channel or 1Gb iSCSI. VMware integration simplifies virtualised environments. Not suited for buyers who need hardware-assisted compression, data-at-rest encryption, or NVMe flash performance.

Deciding Specification

Maximum throughput reaches 8GB/s with latency under 70µs and up to 400K IOPS. Distributed RAID 1, 5 and 6 protect the 20TB raw capacity. Remote replication supports synchronous and asynchronous mirroring.

Highlights

  • 20TB raw capacity from twelve 2.4TB 10K SAS drives
  • 64GB cache accelerates read-intensive storage workloads
  • Dual active controllers deliver continuous availability
  • 16Gb Fibre Channel plus 1Gb iSCSI host connectivity
  • 400K IOPS with sub-70µs latency for demanding applications

Specifications

BrandIBM
SeriesFlashSystem
Model5015 SAS HDD 20TB
Form Factor2U Rackmount
WorkloadStorage Server
2.5" BaysCapacity: up to 20TB
Cache: 64GB
Drive Configuration: 12 x 2.4TB 10K SAS HDD
Host Connections: 1GB iSCSI, 16GB Fiber Channel
Drives Supported: 2.5-inch flash drives, SFF 2.5-inch disk drives, LFF 3.5-inch disk drives
Connectivity Supported: 1Gb ISCI, 10Gb ISCSI, 16Gb Fiber Channel, 12Gb SAS
Max IOPs: 400K IOPs
RAID levels: Distributed RAID 1, 5 and 6
Min latency: Under 70µs
Max bandwidth: 8GB/s
FeaturesData Reduction Pools (Compression, DeDuplication, Thin Provisioning, UNMAP): No
Hardware Assisted Compression: No
Encryption: No
VMWare Integration: Yes
IBM Safeguarded Copy: No
CyberVault Support for Cyber Resiliency: No
Remote Replication (Synchronous Metro Mirror, Asynchronous Global Mirror): Yes
Hyperswap High Availability: No
NVMe Flash: No
FC-NVMe Host Connections: No
Easy Tier AI-driven automated tiering: Yes
Storage Class Memory: No
Transparent Data Migration: Yes
Red Hat OpenShift Container Integration: Yes
Scale-out Clustering: No
Heterogenous Support for >500 storage syste
Shipping weight18.14 kg
Package size483 × 432 × 102 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I verify the 400K IOPs and sub-70µs latency after installation?

Run the built-in performance monitoring tools to confirm the system reports 400K IOPs and latency under 70µs during typical workloads.

Which drives and cables are included versus what I must purchase separately?

The unit ships with 12 x 2.4TB 10K SAS HDDs, 64GB cache, dual active controllers, 2 x 4-port 16Gb Fibre Channel cards and 8 x 5m OM3 LC cables; additional 2.5-inch flash drives, SFF 2.5-inch or LFF 3.5-inch drives must be bought separately.

Should I choose the 20TB configuration or a different capacity for my workload?

The 20TB model delivers 12 x 2.4TB SAS HDDs, 64GB cache and 400K IOPs; select it when you need that raw capacity and performance envelope, otherwise consider a lower-capacity variant if your dataset is smaller.
