A pair of thin multicoloured flexible antenna strips with adhesive backing and 30cm cables ending in IPEX1 connectors

HighZer0 Electronics

HighZer0 Electronics RFANT08Z+M1 IPEX1 30cm 1-Pair network antenna

SKU CH-PS81-SKWD2

Internal WiFi antenna pair with IPEX1 connectors and 30 cm cables for mini-PCIe cards, 2.5 dBi gain across 2.4 GHz, 5 GHz, 5.8 GHz and 6 GHz bands

  • TypeWireless Card Antenna
  • ColorMulticoloured
  • FeaturesLightweight,Flexible,Adhesive Backing
  • IPEX1 / MHF1 / U.FL fit for mini-PCIe cards like 7260HMW
  • 5dBi omnidirectional gain across 2.4, 5, 5.8 and 6GHz bands
  • 30cm RF1.13 cables with adhesive pads for hidden internal routing
  • 50 Ohm impedance, SWR < 2 for stable reception
  • Not for IPEX4 / MHF4 on AX200, AX210, BE200, WiFi 6E or WiFi 7 cards

Internal antenna pair for mini-PCIe cards

This HighZer0 Electronics antenna set replaces or repairs internal WiFi antennas in motherboards, desktops, laptops, routers, and small form factor builds. It is designed for mini-PCIe or Half-Mini PCIe wireless cards that use IPEX1, MHF1, or first-generation U.FL connectors. The 30cm flexible cables with adhesive pads install cleanly inside tight enclosures without external posts.

Upgrade from damaged or missing internal antennas

Swap this set in when original antenna cables are broken, disconnected, or absent from a compatible wireless card such as the 7260HMW, 6235ANHMW, 6205ANHMW, 6300AGN, 633ANHMW, 6200AGN, or 6230ANHMW. The jump is worth it if you need a concealed internal solution supporting 2.4GHz, 5GHz, 5.8GHz, and 6GHz WiFi and Bluetooth with 2.5dBi gain and SWR under 2.

Check connector type and card form factor first

Verify your wireless card uses IPEX1, MHF1, or U.FL ports and is a mini-PCIe or Half-Mini PCIe style adapter. This set will not fit IPEX4 or MHF4 connectors found on many M.2 NGFF cards including AX200, AX210, BE200, WiFi 6E, and WiFi 7 models. Measure available space for the 30cm cable routing and adhesive pad placement.

Highlights

  • IPEX1 / MHF1 / U.FL fit for mini-PCIe cards like 7260HMW
  • 5dBi omnidirectional gain across 2.4, 5, 5.8 and 6GHz bands
  • 30cm RF1.13 cables with adhesive pads for hidden internal routing
  • 50 Ohm impedance, SWR < 2 for stable reception
  • Not for IPEX4 / MHF4 on AX200, AX210, BE200, WiFi 6E or WiFi 7 cards

Specifications

BrandHighZer0 Electronics
ModelRFANT08Z+M1
TypeWireless Card Antenna
ColorMulticoloured
FeaturesLightweight,Flexible,Adhesive Backing

Questions about this item

What connector type does the antenna cable use to attach to the wireless card?

The antenna cable uses an IPEX1 connector, also known as MHF1 or 1st Generation U.FL, for attachment to compatible mini-PCIe or Half-Mini PCIe wireless cards.

How do you secure the antenna pads inside the chassis during installation?

Peel the protective liner from the double-sided adhesive pad on each antenna and press it firmly onto a clean, flat surface inside the case or laptop housing to lock placement and conceal the wiring.

When would the adhesive pads need to be replaced?

Replace the adhesive pads if they lose grip after repeated repositioning, during a motherboard swap, or when moving the antenna set to a different enclosure.
